TABLE OF CONTENTS Rev. 10.5.2022 LAD-RAF, MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Page 9 of 19
FIG. 6: LAD-RAF-9-24-P, LAD-RAF-9-24-P-
EZ, LAD-RAF-9-24-G, & LAD-RAF-9-
24-G-EZ EXPLODED VIEW & BILL OF
MATERIALS
Item
Part no.
Description
Quantity
1
44-014-400
44-014-403
Base support:
LAD-RAF-9-24-P & LAD-RAF-9-24-G
LAD-RAF-9-24-P-EZ & LAD-RAF-9-24-G-EZ
2
2
2
44-647-018
44-647-026
44-647-032
44-647-042
Weldment, 9-step frame:
LAD-RAF-9-24-P
LAD-RAF-9-24-G
LAD-RAF-9-24-P-EZ
LAD-RAF-9-24-G-EZ
1
1
1
1
3
11059
5
/
16
in. – 18 UNC x 1
1
/
2
in. HHCS #2 zinc-plated bolt
18
4
37021
5
/
16
in. – 18 zinc-plated #2 nylon lock nut
22
5
11053
5
/
16
in. – 18 UNC x
3
/
4
in. HHCS #2 zinc-plated bolt
4
6
44-112-007
Wheel axle
1
7
16-132-310
10 in. x 2
1
/
2
in. 16mm steel hub
2
8
65125
3
/
16
in. x 1
1
/
2
in. zinc-plated cotter pin
2
9
99-024-027
1 in. x 1 in., 60 Duro. square cap
2
10
99-025-025
1 in. plastic plug
2
11
44-514-314
Weldment, frame, back platform
1
12
44-524-045
44-524-051
Weldment, handrail:
LAD-RAF-9-24-P & LAD-RAF-9-24-G
LAD-RAF-9-24-P-EZ & LAD-RAF-9-24-G-EZ
2
2
13
44-514-320
Weldment, back leg, 9-step
1
14
11108
3
/
8
in. – 16 UNC x 1
3
/
8
in. zinc-plated hex cap screw
2
15
33008
3
/
8
in. USS zinc-plated flat washer
2
16
99-051-005
1
/
2
in. x 8 in. hook-and-loop fastening strap
2
