FIG. 8: LAD-RAF-11-24-P, LAD-RAF-11-24-P-EZ,
LAD-RAF-11-24-G, & LAD-RAF-11-24-G-EZ
EXPLODED VIEW & BILL OF MATERIALS
Item
Part no.
Description
Qty.
Item
Part no.
Description
Qty.
1
44-647-020
44-647-028
44-647-036
44-647-044
Weldment, 11-step frame:
LAD-RAF-11-24-P
LAD-RAF-11-24-G
LAD-RAF-11-24-P-EZ
LAD-RAF-11-24-G-EZ
1
1
1
1
11 44-514-314 Weldment, frame, back platform 1
2
44-524-047
44-524-053
Weldment, handrail:
LAD-RAF-11-24-P & LAD-RAF-11-24-G
LAD-RAF-11-24-P-EZ & LAD-RAF-11-24-G-EZ
2
2
12 44-514-322 Weldment, back leg, 11-step: 1
3 11059
5
/
16
in. – 18 UNC x 1
1
/
2
in. HHCS #2 zinc-
plated bolt
18 13
44-014-402
44-014-515
Base support:
LAD-RAF-11-24-P & LAD-RAF-11-24-G
LAD-RAF-11-24-P-EZ & LAD-RAF-11-24-
G-EZ
2
4 37021
5
/
16
in. – 18 zinc-plated #2 nylon lock
nut
22 14 11053
5
/
16
in. – 18 UNC x
3
/
4
in. HHCS #2
zinc-plated bolt
2
5 11055
5
/
16
in. – 18 UNC x 1 in. HHCS #2 zinc-
plated bolt
2 15 11108
3
/
8
in. – 16 UNC x 1
3
/
8
in. zinc-plated
hex cap screw
2
6
44-112-007
Wheel axle
1
16
33008
3
/
8
in. USS zinc-plated flat washer
2
7
16-132-310
10 in. x 2
1
/
2
in. 16mm steel hub
2
17
99-051-005
1
/
2
in. x 8 in. hook-and-loop strap
2
8
65125
3
/
16
in. x 1
1
/
2
in. zinc-plated cotter pin
2
18
44-514-310
Assembly, outrigger, right side
1
9
99-024-027
1 in. x 1 in., 60 Duro. square cap
2
19
44-514-311
Assembly, outrigger, left side
1
10
99-025-025
1 in. plastic plug
2
