Table of Contents Rev. 12.6.2018 LAD-MM, MANUAL
Table of Contents C
opyright 2017 Vestil Manufacturing Co. Page 5 of 13
Exploded View & Bill of Materials:
LAD-MM-5-P & LAD-MM-5-G
LAD-
MM-6-P & LAD-MM-6-G
LAD-MM-7-P & LAD-MM-7-G
*NOTE: Diagram shows LAD-MM-5-P.
Item
Part no.
Description
Qty.
1
44-647-007
44-647-011
44-647-008
44-647-012
44-647-009
44-647-013
Weldment, step frame:
LAD-MM-5-P
LAD-MM-5-G
LAD-MM-6-P
LAD-MM-6-G
LAD-MM-7-P
LAD-MM-7-G
1
1
1
1
1
1
2
44-514-302
44-514-303
44-514-304
Weldment, back leg:
5-step, 26” step: LAD-MM-5-P & LAD-MM-5-G
6-step, 26” step: LAD-MM-6-P & LAD-MM-6-G
7-step, 26” step: LAD-MM-7-P & LAD-MM-7-G
1
1
1
3
44-524-057
44-524-039
44-524-040
Weldment, handrail:
LAD-MM-5-P & LAD-MM-5-G
LAD-MM-6-P & LAD-MM-6-G
LAD-MM-7-P & LAD-MM-7-G
2
2
2
4
08-145-008
Snap hook,
1
/
4
”
2
5
16-132-009
Wheel, PP-4/1.25-W
2
6
44-014-320
44-014-238
44-014-243
Frame, base support:
LAD-MM-5-P & LAD-MM-5-G
LAD-MM-6-P & LAD-MM-6-G
LAD-MM-7-P & LAD-MM-7-G
2
2
2
7
99-024-027
Square cap, 1” x 1”, 60 Duro.
2
8
99-025-025
1” plastic plug
4
9
99-145-031
3
/
16
” chain 24”
1
10
11055
Hex bolt, gr, A, zinc plated,
5
/
16
”-18 x 1”
4
11
11060
Hex bolt, HHCS,
5
/
16
”-18UNC x 1
3
/
4
”
14
12
11113
Hex bolt, gr. A, plain finish,
3
/
8
”-16 x 2
1
/
2
”
2
13
33006
Flat washer, zinc plated, USS,
5
/
16
”
4
14
37021
Nylon insert lock nut, gr. 2, zinc finish,
5
/
16
”-18
18
15
37024
Nylon insert lock nut, gr. 2, zinc finish,
3
/
8
”-16
2
