Table of Contents Rev. 11/30/2018 LAD-FM, MANUAL
Table of Contents Copyright 2017 Vestil Manufacturing Co. Page 8 of 18
FIG. 5: LAD-FM-108 exploded view and bill of materials
Item
Part no.
Description
Qty.
Item
Part no.
Description
Qty.
1
44-514-407
Weldment, frame, top steps
1
16
44-514-409
Weldment, frame, back assembly
1
2
44-514-408
Weldment, frame, steps, lower
1
17
44-516-024
Assembly, bracket, handrail splice
2
3 44-014-544 Frame, side stiffener, formed 2 18 37024
Nylon insert lock nut, grade 2, zinc
finish,
3
/
8
” – 16
32
4 44-514-376 Weldment, frame, back assembly 1 19 33008
Flat washer, low carbon, USS, zinc
plated,
3
/
8
”
28
5
44-112-010
Pin, main hinge
1
20
11112
3
/
8
” - 16 x 2
1
/
4
” HHCS bolt
4
6
16-132-009
PP-4/1.25-W
2
21
33018
USS flat washer, zinc plated,
3
/
4
”
2
7 44-514-277
Weldment, frame, roller bracket,
right
1 22 11113
Hex bolt, grade A, plain finish,
3
/
8
” –
16 x 2
1
/
2
”
10
8
44-016-081
Bracket, handrail mount
4
23
11115
3
/
8
” – 16 x 3” HHCS bolt
1
9 44-524-169 Weldment, handrail, bottom 2 24 36106
Hex nut, grade A, zinc plated,
3
/
8
” –
16
1
10
44-524-093
Weldment, handrail, hinge, right
1
25
65127
Cotter pin, zinc plated,
3
/
16
” x 2”
2
11 44-524-094 Weldment, handrail, hinge, left 1 26 11107
Hex bolt, grade A, zinc finish,
3
/
8
” –
16 x 1
1
/
4
”
2
12 44-514-278
Weldment, frame, roller bracket,
left
1 27 33006 Flat washer, zinc plated, USS,
5
/
16
” 2
13 44-544-001 Weldment, push bar 1 28 37018
Nylon lock nut, grade 2, zinc finish,
1
/
4
” – 20
1
14 44-524-004 Weldment, handle, rail assy. 2 29 11009
Hex bolt, grade A, zinc plated,
3
/
8
”-
20 x 1
1
/
2
”
1
15 44-001-215 Jack, manual, ratcheting, 35” long 1 30 24092
BHCS, utility grade, black oxide,
3
/
8
”
– 16 x 1”
16
