Table of Contents Rev. 11/18/2019 LAD (6-12 STEPS), MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 6 of 20
FIG. 3: LAD-7-14-G, LAD-7-14-P, LAD-7-21-G & LAD-7-21-P Exploded View and Bill of Materials
Item
Part no.
Description
Quantity
1
44-647-166
44-647-159
44-647-225
44-647-219
Weldment, 7-step frame:
LAD-7-14-G
LAD-7-14-P
LAD-7-21-G
LAD-7-21-P
1
2
44-524-123
44-524-129
Weldment, handrail, 7-step ladder:
LAD-7-14-G & LAD-7-14-P
LAD-7-21-G & LAD-7-21-P
2
3
44-514-314
Weldment, frame, back platform
1
4
44-514-397
Weldment, back leg, 7-step
1
5
44-014-320
44-014-238
Frame, base support:
LAD-7-14-G & LAD-7-14-P
LAD-7-21-G & LAD-7-21-P
2
6
44-514-354
Weldment, frame, caster pivot foot lock
1
7
99-024-027
1” x 1”, 60 duro. square cap
2
8
99-025-025
1” plastic plug
2
9
28-146-003
Spring
2
10
44-112-007
Wheel axle
1
11
16-132-310
10” x 2
1
/
2
” wheel with 16mm steel hub
2
12
16-132-164
Caster, front
2
13
20-027-005
Roller guide
4
14
11059
5
/
16
” – 18 x 1
1
/
2
” zinc-plated #2 bolt
14
15
37021
5
/
16
” – 18 zinc-plated #2 Nylon lock nut
22
16
11108
3
/
8
” – 16 UNC x 1
3
/
8
” zinc-plated hex cap
screw
2
17
33008
3
/
8
” zinc-plated USS flat washer
8
18
11061
5
/
16
” – 18 x 2” HHCS #2 zinc-plated bolt
4
19
33456
1
1
/
8
” I.D. 10 gauge machine bushing
2
20
65127
3
/
16
” x 2” zinc-plated cotter pin
2
21
11105
3
/
8
” – 16 x 1in. hex head bolt
2
22
36106
3
/
8
” – 16 zinc-plated hex nut
2
23
26329
3
/
8
” shoulder x
3
/
4
” x
5
/
16
” – 18 bolt
2
24
37024
3
/
8
” Nylock insert nut
4
25
65125
3
/
16
” x 1
1
/
2
” zinc-plated cotter pin
2
26
11053
5
/
16
” – 18 x
3
/
4
” HHCS #2 zinc-plated bolt
2
27
33006
5
/
16
” USS zinc-plated USS flat washer
2
28
11055
5
/
16
” – 18 x 1” HHCS #2 zinc-plated bolt
2
NOTE: See FIG. 1 on p. 4 for a detailed exploded view of the Foot Lock
Mechanism.
See FIG. 1 on p. 4
