Table of Contents Rev. 11/18/2019 LAD (6-12 STEPS), MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 14 of 20
Step 2: Fasten the back leg weldment to the stair frame weldment with
5
/
16
in. hardware. Be sure to orient the
back leg weldment as shown below.
Step 3: Fasten the base supports to the ladder assembly with
5
/
16
in. – 18 hardware as shown below.
5
/
16
in.-18 x 1
1
/
2
in. bolt (11062)
Back leg
weldment
Stair frame
weldment
+
5
/
16
in.-18 lock nut (37021)
Base
bracket
Base
support
+
5
/
16
in.
–
18 lock nut (37021)
5
/
16
in. – 18 x 1in. bolt (11055) AND
5
/
16
in. flat washer (33006)
Ladder
assembly
3
/
8
in. – 16 x 1in. bolt (11055);
5
/
16
in. flat
washer (33006); AND
5
/
16
in. – 18 lock nut
(37021)
Axle
receiver
