Table of Contents Rev. 12/2/2019 LAD (13-16 STEPS), MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 14 of 18
Step 9: Fasten the upper and lower portions of the handrails to the ladder assembly with
5
/
16
” hardware (11060; 37021).
Attach snap hooks to
the hook rings on the
handrails
Hook
ring
Snap
hook
To connect the upper and lower handrails, first slide a 1”
tube sleeve (99-025-028) onto the end of each upper
handrail. Next, a) press the splice (44-625-002) into the
handrails; and b) tighten the connection by turning the
5
/
16
”
set screws. Then, slide the tube sleeves over the
junctions
.
1” tube sleeve
(black). Slide onto
ends of upper
handrails
Lower
handrail
5
/
16
” – 18 UNC x 1
3
/
4
” (11060) &
5
/
16
” – 18 lock nut (37021)
Splice
Insert splice into
upper handrail
Insert into lower handrail
Set
screw
a.
b.
Cross bar
Upper
handrail
5
/
16
” – 18 UNC x
1
3
/
4
” (11060) and
5
/
16
” – 18 lock nut
(37021)
Step 8: Install the toeboard at the top of the ladder; then set the ladder upright. The ladder is quite heavy and
requires at least 2 people to lift it.
Toeboard
5
/
16
in. lock nut
(37021)
5
/
16
in. flat
washer
(33006)
5
/
16
in. – 18 x 2
1
/
4
in.
(11062)
5
/
16
in. flat
washer
(33006)
Set
screw
