Table of Contents Rev. 12/2/2019 LAD (13-16 STEPS), MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 8 of 18
Item
Part no.
Description
Quantity
1
44-647-285
44-647-284
44-647-286
44-647-287
Weldment, step, 50°, top 8 steps:
LAD-16-14-G-EZ
LAD-16-14-P-EZ
LAD-16-21-G-EZ
LAD-16-21-P-EZ
1
1
1
1
2
44-647-283
44-647-282
Weldment, 16-step frame, bottom, 50°:
LAD-16-14-G-EZ & LAD-16-21-G-EZ
LAD-16-14-P-EZ & LAD-16-21-P-EZ
1
1
3
44-514-314
Weldment, frame, back platform
2
4
44-514-354
Weldment, frame, caster pivot foot lock
1
5
44-514-399
Assembly, frame, outrigger, right
1
6
44-514-400
Assembly, frame, outrigger, left
1
7
44-514-401
Weldment, support frame, upper 8 steps
1
8
44-514-405
Weldment, support frame, lower 16 steps
1
9
44-524-161
Weldment, handrail, 50° climb, lower, 16 steps
2
10
44-524-162
44-524-163
Weldment, handrail, 50° climb, top 8 steps:
LAD-16-14-G-EZ & LAD-16-14-P-EZ
LAD-16-21-G-EZ & LAD-16-21-P-EZ
2
2
11
44-645-002
Assembly, handrail splice joint
2
12
08-145-008
1
/
4
” snap hook
2
13
16-132-164
Caster, front
2
14
16-132-310
10” x 2
1
/
2
” wheel with 16mm steel hub
2
15
20-027-005
Roller guide
4
16
28-146-003
Spring, release
2
17
44-012-008
Hinge plates, connector
2
18
44-014-595
Frame, tube, horizontal, vertical center, crimped
1
19
44-014-596
Frame, tube, horizontal, vertical center, crimped
2
20
44-014-605
44-014-606
Frame, tube, horizontal back, crimped
LAD-16-14-G-EZ & LAD-16-14-P-EZ
LAD-16-21-G-EZ & LAD-16-21-P-EZ
4
4
21
44-014-610
Frame, tube, horizontal, crimped
2
22
44-015-001
Toeguard, removable back formed, formed
1
23
44-016-109
Bracket, mid-ladder, outside
2
24
44-016-110
Bracket, mid-ladder, inside, formed
2
25
44-112-014
14-16 step wheel axle
1
26
99-024-027
1” x 1”, 60 duro. square cap
2
27
99-025-025
1” plastic plug (black)
2
28
99-025-028
Grip, 1” square tube sleeve
2
29
99-145-031
3
/
16
” chain, 24”
1
30
11010
1
/
4
” – 20 x 1
3
/
4
” HHCS #2 zinc-plated bolt
4
31
11055
5
/
16
” – 18 x 1” HHCS #2 zinc-plated bolt
18
32
11060
5
/
16
” – 18 x 1
3
/
4
” HHCS hex bolt
26
33
11062
5
/
16
” – 18 x 2
1
/
4
” HHCS #2 zinc-plated bolt
4
34
11105
3
/
8
” – 16 x 1in. hex head bolt
2
35
11107
3
/
8
” – 16 x 1
1
/
4
” HHCS #2 zinc-plated bolt
16
36
26329
3
/
8
” shoulder x
3
/
4
” x
5
/
16
” – 18 bolt
2
37
33006
5
/
16
” USS zinc-plated USS flat washer
10
38
33008
3
/
8
” zinc-plated USS flat washer
24
39
33456
1
1
/
8
” I.D. 10 gauge machine bushing
2
40
33622
3
/
8
” lock washer
2
41
37018
1
/
4
” – 20 UNC zin-plated nylock nut
4
42
37021
5
/
16
” – 18 zinc-plated #2 Nylon lock nut
50
43
37024
3
/
8
” Nylock insert nut
16
44
65127
3
/
16
” x 2” zinc-plated cotter pin
4
NOTE: See FIG. 1 on p. 4 for a detailed view of the Foot Lock Mechanism
Also see FIG. 1 on p. 4
FIG. 5: LAD-16-14-P-EZ, LAD-16-14-G-EZ, LAD-16-21-P-EZ, &
LAD-16-21-G-EZ Exploded View and Bill of Materials
(44-006-572)
