Table of Contents Rev. 12/8/2020 LAD (13-16 STEPS), MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 7 of 19
Item
Part no.
Description
Quantity
1
44-647-258
44-647-257
Weldment, 58°, upper (8) steps:
LAD-15-14-G
LAD-15-14-P
1
1
2
44-647-268
44-647-267
Weldment, lower (7) steps:
LAD-15-14-G
LAD-15-14-P
1
1
3
44-514-314
Weldment, frame, back platform
2
4
44-514-354
Weldment, frame, caster pivot foot lock
1
5
44-514-399
Assembly, frame, outrigger, right
1
6
44-514-400
Assembly, frame, outrigger, left
1
7
44-514-401
Weldment, frame, upper 8 steps
1
8
44-514-404
Weldment, frame, lower 7 steps
1
9
44-524-147
Weldment, handrail, 58° climb, top:
2
10
44-524-153
Weldment, handrail, 15 steps
2
11
44-645-001
Assembly, handrail splice joint
2
12
44-012-008
Hinge plates, connector
2
13 44-014-595
Frame tube, horizontal, vertical center,
crimped
2
14
44-014-597
Frame, tube, horizontal back, crimped:
5
15
44-014-601
Frame, tube, horizontal, crimped
2
16
44-015-001
Toeboard, removable back formed, formed
1
17
44-016-109
Bracket, mid-ladder, outside
2
18
44-016-110
Bracket, mid-ladder, inside, formed
2
19
44-112-014
14-16 step wheel axle
1
20
08-145-008
1
/
4
” snap hook
2
21
16-132-164
Caster, front
2
22
16-132-310
10” x 2
1
/
2
” wheel with 16mm steel hub
2
23
20-027-005
Roller guide
4
24
28-146-003
Spring, release
2
25
99-024-027
1” x 1”, 60 duro. square cap
2
26
99-025-025
1” plastic plug (black)
2
27
99-025-028
Grip, 1” square tube sleeve
2
28
99-145-031
3
/
16
” chain, 24”
1
29
11010
1
/
4
” – 20 x 1
3
/
4
” HHCS #2 zinc-plated bolt
4
30
11053
5
/
16
” – 18 x
3
/
4
” HHCS #2 zinc-plated bolt
18
31
11060
5
/
16
” – 18 x 1
3
/
4
” HHCS hex bolt
28
32
11062
5
/
16
” – 18 x 2
1
/
4
” HHCS #2 zinc-plated bolt
4
33
11105
3
/
8
” – 16 x 1in. hex head bolt
12
34
11107
3
/
8
” – 16 x 1
1
/
4
” HHCS #2 zinc-plated bolt
4
35
11109
3
/
8
” – 16 x 1
1
/
2
” HHCS #2 zinc-plated bolt
2
36
26329
3
/
8
” shoulder x
3
/
4
” x
5
/
16
” – 18 bolt
2
37
33006
5
/
16
” USS zinc-plated USS flat washer
8
38
33008
3
/
8
” zinc-plated USS flat washer
26
39
33456
1
1
/
8
” I.D. 10 gauge machine bushing
2
40
36106
3
/
8
” – 16 zinc-plated hex nut
2
41
37018
1
/
4
” – 20 UNC zin-plated nylock nut
4
42
37021
5
/
16
” – 18 zinc-plated #2 Nylon lock nut
50
43
37024
3
/
8
” Nylock insert nut
16
44
65125
3
/
16
” x 1
1
/
2
” zinc-plated cotter pin
4
NOTE: See FIG. 1 on p. 4. For a detailed view of the Foot Lock Mechanism.
FIG. 4: LAD-15-14-G & LAD-15-14-P
Exploded View and Bill of Materials
