Table of Contents Rev. 12/8/2020 LAD (13-16 STEPS), MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 5 of 19
Item
Part no.
Description
Quantity
1
44-647-256
44-647-255
44-647-258
44-647-257
Weldment, 58°, upper (8) steps:
LAD-13-14-G
LAD-13-14-P
LAD-13-21-G
LAD-13-21-P
1
1
1
1
2
44-647-264
44-647-263
Weldment, lower (5) steps:
LAD-13-14-G & LAD-13-21-G
LAD-13-14-P & LAD-13-21-P
1
1
3
44-514-314
Weldment, frame, back platform
2
4
44-514-354
Weldment, frame, caster pivot foot lock
1
5
44-514-399
Assembly, frame, outrigger, right
1
6
44-514-400
Assembly, frame, outrigger, left
1
7
44-514-401
Weldment, support frame, upper 8 steps
1
8
44-514-402
Weldment, support frame, lower 13 steps
1
9
44-524-147
44-524-148
Weldment, handrail, 58° climb, top:
LAD-13-14-G & LAD-13-14-P
LAD-13-21-G & LAD-13-21-P
2
2
10
44-524-151
Weldment, handrail, 13 steps
2
11
44-645-001
Assembly, handrail splice joint
2
12
44-012-008
Hinge plates, connector
2
13
44-014-593
Frame tube, horizontal, vertical center, crimped
2
14
44-014-597
44-014-598
Frame, tube, horizontal back, crimped:
LAD-13-14-G & LAD-13-14-P
LAD-13-21-G & LAD-13-21-P
4
4
15
44-014-599
Frame, tube, horizontal, crimped
2
16
44-014-601
Frame, tube, horizontal, crimped
1
17
44-015-001
Toeboard, removable back formed, formed
1
18
44-016-109
Bracket, mid-ladder, outside
2
19
44-016-110
Bracket, mid-ladder, inside, formed
2
20
44-112-014
14-16 step wheel axle
1
21
08-145-008
1
/
4
” snap hook
2
22
16-132-164
Caster, front
2
23
16-132-310
10” x 2
1
/
2
” wheel with 16mm steel hub
2
24
20-027-005
Roller guide
4
25
28-146-003
Spring, release
2
26
99-024-027
1” x 1”, 60 duro. square cap
2
27
99-025-025
1” plastic plug (black)
2
28
99-025-028
Grip, 1” square tube sleeve
2
29
99-145-031
3
/
16
” chain, 24”
1
30
11010
1
/
4
” – 20 x 1
3
/
4
” HHCS #2 zinc-plated bolt
4
31
11053
5
/
16
” – 18 x
3
/
4
” HHCS #2 zinc-plated bolt
18
32
11060
5
/
16
” – 18 x 1
3
/
4
” HHCS hex bolt
24
33
11062
5
/
16
” – 18 x 2
1
/
4
” HHCS #2 zinc-plated bolt
4
34
11105
3
/
8
” – 16 x 1in. hex head bolt
12
35
11107
3
/
8
” – 16 x 1
1
/
4
” HHCS #2 zinc-plated bolt
4
36
11109
3
/
8
” – 16 x 1
1
/
2
” HHCS #2 zinc-plated bolt
2
37
26329
3
/
8
” shoulder x
3
/
4
” x
5
/
16
” – 18 bolt
2
38
33006
5
/
16
” USS zinc-plated USS flat washer
8
39
33008
3
/
8
” zinc-plated USS flat washer
26
40
33456
1
1
/
8
” I.D. 10 gauge machine bushing
2
41
36106
3
/
8
” – 16 zinc-plated hex nut
2
42
37018
1
/
4
” – 20 UNC zin-plated nylock nut
4
43
37021
5
/
16
” – 18 zinc-plated #2 Nylon lock nut
46
44
37024
3
/
8
” Nylock insert nut
16
45
65125
3
/
16
” x 1
1
/
2
” zinc-plated cotter pin
4
NOTE: See FIG. 1 on p. 4 for a detailed exploded view of the Foot Lock Mechanism.
FIG. 2: LAD-13-14-P, LAD-13-14-G, LAD-13-21-P, & LAD-13-21-G
Exploded View and Bill of Materials
