Table of Contents Rev. 11/18/2019 LAD-EZ (6-12 STEPS), MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 7 of 20
Item
Part no.
Description
Quantity
1
44-647-238
44-647-232
44-647-250
44-647-244
Weldment, 8-step frame, 50°:
LAD-8-14-G-EZ
LAD-8-14-P-EZ
LAD-8-21-G-EZ
LAD-8-21-P-EZ
1
2
44-514-314
Weldment, frame, back platform
1
3
44-514-319
Weldment, back leg, 8-step
1
4
44-514-354
Weldment, frame, caster pivot foot lock
1
5
44-524-136
44-524-142
Weldment, handrail, 8-step ladder:
LAD-8-14-G-EZ & LAD-8-14-P-EZ
LAD-8-21-G-EZ & LAD-8-21-P-EZ
2
6
16-132-164
Caster, front
2
7
16-132-310
10” x 2
1
/
2
” wheel with 16mm steel hub
2
8
20-027-005 Roller guide 4
9
28-146-003 Spring, release 2
10
44-014-401
44-014-402
Frame, base support:
LAD-8-14-G-EZ & LAD-8-14-P-EZ
LAD-8-21-G-EZ & LAD-8-21-P-EZ
2
11
44-112-007 Wheel axle 1
12
99-024-027
1” x 1”, 60 duro. square cap
2
13
99-025-025
1” plastic plug
2
14
11055
5
/
16
” – 18 x 1” HHCS #2 zinc-plated bolt
4
15
11060
5
/
16
” – 18 x 1
3
/
4
” HHCS #2 zinc-plated
bolt
18
16
11105
3
/
8
” – 16 x 1in. hex head bolt
2
17
11107
3
/
8
” – 16 UNC x 1
1
/
4
” zinc-plated hex bolt 2
18
26329
3
/
8
” shoulder x
3
/
4
” x
5
/
16
” – 18 bolt
2
19
33006
5
/
16
” USS zinc-plated USS flat washer
4
20
33008
3
/
8
” zinc-plated USS flat washer
6
21
33456
1
1
/
8
” I.D. 10 gauge machine bushing
2
22
33622
3
/
8
” zinc—plated lock washer
2
23
37021
5
/
16
” – 18 zinc-plated #2 Nylon lock nut
24
24
37024
3
/
8
” Nylock insert nut
4
25
65127
3
/
16
” x 2” zinc-plated cotter pin 4
NOTE: See FIG. 1 on p. 4 for a detailed exploded view of the Foot Lock
Mechanism.
FIG. 4: LAD-8-14-G-EZ, LAD-8-14-P-EZ, LAD-8-21-G-EZ, & LAD-8-21-P-EZ Exploded View and Bill of Materials
See FIG. 1 on p. 4
