TABLE OF CONTENTS Rev. 2/22/2024 JIB-FM, MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Co. Page 4 of 12
FIG. 3: JIB-FM-10 EXPLODED VIEW AND BILL OF MATERIALS
Item
Part No.
Description
Qty.
1
28-514-047
Weldment, floor mount subassembly
(“Mast”)
1
2
28-514-045
Weldment, pivot subassembly (“Socket”)
1
3
28-514-166
Weldment, I-beam subassembly (“Boom”)
1
4
05-527-300
Roller, assembly
2
5
33012
Flat washer, low carbon, zinc finish,
1
/
2
”
4
6
33626
Lock washer, zinc plated,
1
/
2
”
4
7
36310
1
/
2
”-13 UNC grade 5, hex nut, zinc plated
4
8
33098
1
1
/
8
” SAE flat washer, zinc-plated
2
9
28-110-
001-001
Inner bearing
1
10
13211
1
/
2
” -13x2” HHCS #5, zinc plated bolt
4
11
64319
Pin, spring,
3
/
8
” x 3”
2
FIG. 2: JIB-FM-6 EXPLODED VIEW AND BILL OF MATERIALS
Item
Part No.
Description
Qty.
1
28-514-050
Weldment, floor mount subassembly (“Mast”)
1
2
28-514-044
Weldment, pivot subassembly (“Socket”)
1
3
05-527-300
Roller, assembly
2
4
33012
Flat washer, low carbon, zinc finish,
1
/
2
”
4
5
33626
Lock washer, zinc plated,
1
/
2
”
4
6
36310
1
/
2
”-13 UNC grade 5, hex nut, zinc plated
4
7
33098
1
1
/
8
” SAE flat washer, zinc-plated
2
8
28-514-049
Weldment, I-beam subassembly (“Boom”)
1
9
28-110-001-001
Inner bearing
1
10
13211
1
/
2
” -13x2” HHCS #5, zinc plated bolt
4
11
64319
Pin, spring,
3
/
8
” x 3”
2
