Table of Contents Rev. 5/11/2020 HIPM, MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Corp. Page 9 of 18
*FIG. 4A: AC modular power unit exploded parts diagram and parts list
*Refer to separate MPU-GEN2 manual if your HIPM was manufactured after 12-1-2018.
Item
no.
Part no. Description
Quantity
1
99-016-933
Base bracket
1
2
21-034-008
Electrical box (see FIG. 6B)
1
3
21-034-005
AC adaptor plug
1
4
37927
Tinnerman clip
4
5
99-023-001
Reservoir
1
6
Motor brace
1
7
23255
33687
5
/
16
” – 18 x 1” utility grade bolt
5
/
16
” high collar lock washer
4
4
8
BV-48
Breather
1
9
29185
1
/
4
” – 20 x 1” TPHMS z-plated
screw
1
10
29201
1
/
4
” – 20 x 1
3
/
4
” TPHMS z-plated
screw
1
11
23305
33688
33008
3
/
8
” – 16 x 1” utility grade bolt
3
/
8
” high collar lock washer
3
/
8
” flat washer
2
2
2
12
01-627-010
Manifold (see FIG. 6C)
1
13
01-143-906
Pump
1
14
HS52
Worm gear hose clamp
1
15
091802JY
Fiberglass cover
1
16
ZB2BZ009
Base, contact block
3
17
ZB2BE101
Contact block N.O.
3
18
ZB2BA2C
Operator, black, non-
illuminated
2
19
ZB2BG4C
Key switch, 2-position
1
20
01-134-007
Legend, ON - OFF
1
21
1
22
HS52
Clamp, worm gear
1
23
01-143-906
Pump
1
24
01-627-010
Manifold assembly (exploded
view on p. 12)
1
25
29201
1
/
4
in. – 20 x 1
3
/
4
in. TPHMS
zinc-plated
2
26
29185
1
/
4
in. – 20 x 1in. TPHMS zinc-
plated
2
27
23255
33687
SHCS utility grade
High collar lock washer
4
4
28
152400-03
Molded cord
1
29
150CCTM.OEM
Connector, charge
1
30
3MT ST3540
1in. hook and loop press
10”
