Table of Contents Rev. 5/11/2020 HIPM, MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Corp. Page 17 of 18
2.) When properly connected, the charge LED will indicate the status of charge current flowing to the battery.
• If only the red LED is on, the charger is providing full output to the battery.
• If both the red and green LED's are on, the charger is "topping off" the battery.
• When only the green LED is on, the unit is providing a "float" (maintenance) charge.
• DO NOT leave the charger on for long periods after the battery is fully charged.
3.) Unplug the charger before using the lifter. Failure to do so could cause damage to cords, receptacles, etc.
TROUBLESHOOTING--If the charger does not work:
1) Make sure all battery connections sound.
2) Confirm that the AC power source (e.g. wall socket) is supplying power.
3) Make sure that the fuse is intact. If not, replace it with a fuse having the same rating. The charger fuse will blow if it is connected
in reverse polarity.
4) Determine battery condition. It may take some time before current begins to flow through a highly sulfated battery.
LABELING DIAGRAM
The unit should be labeled as shown in the diagram. However, label content and location are subject to
change so your product might not be labeled exactly as shown. Replace all labels that are damaged, missing, or
not easily readable (e.g. faded). To order replacement labels, contact the technical service and parts department
online at http://www.vestilmfg.com/parts_info.htm
. Alternatively, you may request replacement parts and/or
service by calling (260) 665-7586 and asking the operator to connect you to the PARTS DEPARTMENT.
B: Label 465
A: Label 658
H: Label 287 – Product data label.
C: Label 824
A
B
C
D
E
F
A
B
D
E
G
G
H
D: Label 212
E: Label 208
F: Label 206
G: Label 295
