rev. 11/13/2013 HDU-C, Manual
Copyright 2013 Vestil Manufacturing Corp. Page 7 of 11
HDU-C-12 bill of materials
NOTE: You will receive straight and/or inclined arms as per your order.
HDU-C-14 bill of materials
NOTE: You will receive straight and/or inclined arms as per your order.
Item no. Part no. Description Quantity
1 HDU-1-UR-12 12 ft. double-sided upright 2
2 HDU-2-DB-12 Double-sided base 2
3 HDU-3-BB Back brace 3
4 HDU-4-CB Cross bar 4
5
HSA-C-8 Straight arm as ordered
HIA-C-8 Inclined arm as ordered
HDSA Heavy-duty straight arm as ordered
XHDSA Extra heavy duty straight arm as ordered
6 HDU-6-BOLT M24-2.0 x 40mm bolt 4 per arm
7 HDU-7-WA M24 flat washer 4 per arm
8 HDU-8-LW M24 lock washer 4 per arm
9 HDU-9-HN M24-2.0 hex nut 4 per arm
10 HDU-10-BOLT M17-1.5 x 32mm bolt 14
11 HDU-11-LN M17-1.5 lock nut 14
12 HDU-12-BOLT M17-1.5 x 32mm bolt 14
13 HDU-13-LN M17-1.5 lock nut 14
14 HDU-14-BOLT M30-2.5 x 40mm bolt 12
15 HDU-15-WA M30 flat washer 12
16 HDU-16-LW M30 lock washer 12
17 HDU-17-HN M30-2.5 hex nut 12
Item no. Part no. Description Quantity
1 HDU-1-UR-14 14 ft. double-sided upright 2
2 HDU-2-DB-14 Double-sided base 2
3 HDU-3-BB Back brace 3
4 HDU-4-CB Cross bar 4
5
HSA-C-8 Heavy duty straight arm as ordered
HIA-C-8 Heavy duty inclined arm as ordered
HDSA Heavy duty straight arm as ordered
XHDSA Extra-heavy duty straight arm as ordered
6 HDU-6-BOLT M24-2.0 x 40mm bolt 4 per arm
7 HDU-7-WA M24 flat washer 4 per arm
8 HDU-8-LW M24 lock washer 4 per arm
9 HDU-9-HN M24-2.0 hex nut 4 per arm
10 HDU-10-BOLT M17-1.5 x 32mm bolt 14
11 HDU-11-LN M17-1.5 lock nut 14
12 HDU-12-BOLT M17-1.5 x 32mm bolt 14
13 HDU-13-LN M17-1.5 lock nut 14
14 HDU-14-BOLT M30-2.5 x 40mm bolt 12
15 HDU-15-WA M30 flat washer 12
16 HDU-16-LW M30 lock washer 12
17 HDU-17-HN M30-2.5 hex nut 12
