Table of Contents 5/14/2020 HDD, MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. 7 of 25
FIG. 5: HDD-36-P series portable dumpers exploded view and bill of materials
Item
Part no.
Description
Qty.
Item
Part no.
Description
Qty.
1
09-002-126
Final assembly without power unit
1
15
16-132-216
Caster, 8”, glass filled nylon
2
2
09-514-131
Weldment, frame, stationary
1
16
09-525-009
Weldment, handle bracket, right
1
3
09-512-001
Hinge block assembly
2
17
16-025-028
Handle, push handles, chromed
1
4
09-537-013
Assembly, drum clamp, casting
2
18
09-525-008
Weldment, handle bracket, left
1
5
37039
Nylock nut, zinc-plated,
3
/
4
” – 10
4
19
11055
5
/
16
”–18 x 1” HHCS #2 zinc-plated bolt
2
6
24-612-003
Pin assembly, cylinder
1
20
36104
5
/
16
”–18 grade A zinc-plated hex nut
2
7
09-145-020
Threaded pipe cap
2
21
09-016-169
Bracket, wheel
2
8
01-022-021
Switch, limit, roller arm
1
22
33012
1
/
2
” flat washer, low carbon, zinc finish
20
9
36102
Hex nut, grade A, zinc-plated,
1
/
4
” - 20
1
23
37030
Nylock nut, zinc-plated,
1
/
2
” – 13
10
10
22805
Elevator bolt, limit switch
1
24
11219
1
/
2
”–13 x 4” hex head bolt
10
11
09-545-028
Weldment, subassembly, chute
1
25
16-111-003
Sleeve bearing for 2” wheel
8
12
08-025-008
4-handle bolt, 4”
2
26
99-612-001
3
/
8
”–16 x 5” bolt and nut combo.
2
13 12365
3
/
4
” – 10 x 3” HHCS #5 plain bolt 4 27
99-021-
909-001
Hydraulic cylinder, 2
1
/
2
” x 18” 1
14 16-132-262 6” x 2” glass filled nylon swivel caster 2 28 99-160-097
Modular power unit, GEN2 (display
only)
1
29
31802
Screw, self-tapping screw
2
Pivot
shaft
