Table of Contents 5/14/2020 HDD, MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. 22 of 25
FIG. 12B: AC modular power unit exploded parts diagram and bill of materials
*Refer to MPU-GEN2 manual if your unit was manufactured on or after 12-01-2018.*
Detail view of Electric Box Assembly (2)
Item
Part no.
Description
Qty.
Item
Part no.
Description
Qty.
1
99-016-933
MPU base bracket
1
15
99-024-029
Plastic cover (gray)
1
2
Electric box assembly
1
16
99-034-008
Coil, 24V AC
1
3
21-034-005
Connector, flanged inlet plug
1
17
99-153-006
Valve, pressure relief
1
4
37927
U nut
4
18
99-144-007
O-Ring
1
5
99-023-001
Reservoir
1
19
99-531-005
Filter
1
6
Motor brace
1
20
99-153-038
Flow control, 1.0GPM
1
7
23255
33687
5
/
16
” – 18 x 1” socket head bolt
5
/
16
” lock washer
4
4
21 99-135-003 Motor,
3
/
4
HP 1
8
01-116-003
Breather, vent, brass fitting
1
22
11005
33004
33618
36102
1
/
4
” – 20 - 1” hex head bolt
1
/
4
” flat washer
1
/
4
” lock washer
1
/
4
” – 20 hex nut
6
6
6
6
9 29185
1
/
4
” – 20 x 1” Phillips head truss
machine screw
2
10
29201
1
/
4
” – 20 x 1
3
/
4
” machine screw
2
11
23305
33688
33008
3
/
8
” – 16 x 1” socket head bolt
3
/
8
” lock washer
3
/
8
” flat washer
2
2
2
23
01-127-010
Manifold, LHL standard
1
24
99-153-011
Valve, check, #8, 1 bar spring
1
25
99-144-023
O-ring, large
1
12
01-627-010
LHL manifold assembly
1
26
99-144-022
O-ring
1
13
01-143-906
Hydraulic gear pump
1
27
99-153-015
Valve, cartridge, NC
1
14
99-145-061
Worm gear hose clamp
1
A
71616
10-32 x
5
/
8
” truss head machine screw
4
F
99-034-941
39” rail, din, aluminum
3”
B
01-129-001
Control transformer
1
G
01-029-006
Junction box with screw lid
1
C
132560
Contactor, motor, UL Listed
1
H
99-029-142
Plate, enclosure
1
D
27531
10-32 x
1
/
4
” z-plated machine screw
4
I
99-034-037
Connector, clamp, NM, Romex
4
E
32028
#8 – 18 x
1
/
2
” self-tapping screw
4
Detail view of
Manifold (12)
