Table of Contents 5/14/2020 HDD, MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. 6 of 25
FIG. 3: HDD-60-S series stationary dumpers exploded view and bill of materials
FIG. 4: HDD-72-S series stationary dumpers exploded view and bill of materials
Item Part no. Description Qty.
1 99-002-124
Final assembly without
power unit
1
1.1 09-514-127
Weldment, frame, stationary
1
1.2 09-512-001
Hinge block assembly 2
1.3 09-537-013
Assembly, drum clamp,
casting
2
1.4 37039
Nylock nut, zinc-plated,
3
/
4
”
– 10
4
1.5
24-612-003
Pin assembly, cylinder 1
1.6 09-145-020
Threaded pipe cap 2
1.7 01-022-021
Switch, limit, roller arm 1
1.8 36102
Hex nut, grade A, zinc-
plated,
1
/
4
” - 20
1
1.9
22805 Elevator bolt, limit switch 1
1.10 09-545-031
Weldment, subassembly,
chute
1
1.11 13365
3
/
4
” – 10UNC x 3” zinc-
plated #5 bolt
4
1.12
99-021-
909-001
Hydraulic cylinder, 2
1
/
2
” x
18”
1
2 99-160-097
Modular power unit, GEN2
(display only)
1
3 31802 Screw, self-tapping screw 2
Item Part no. Description Qty.
1 99-002-125
Final assembly without
power unit
1
1.1 09-514-125
Weldment, frame,
stationary
1
1.2 09-512-001 Hinge block assembly 2
1.3 09-537-013
Assembly, drum clamp,
casting
2
1.4 37039
Nylock nut, zinc-plated,
3
/
4
” – 10
4
1.5 24-612-003 Pin assembly, cylinder 1
1.6 09-145-020 Threaded pipe cap 2
1.7 01-022-021 Switch, limit, roller arm 1
1.8 22805 Elevator bolt, limit switch 1
1.9 09-545-031
Weldment, subassembly,
chute
1
1.10 13365
3
/
4
” – 10UNC x 3” zinc-
plated #5 bolt
4
1.11 36102
Hex nut, grade A, zinc-
plated,
1
/
4
” - 20
1
1.12
99-021-909-
001
Hydraulic cylinder, 2
1
/
2
” x
18”
1
2 99-160-097
Modular power unit,
GEN2 (display only)
1
3
31802 Screw, self-tapping screw
2
Pivot
shaft
Pivot
shaft
