Table of Contents 5/14/2020 HDD, MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. 4 of 25
SIGNAL WORDS
This manual uses SIGNAL WORDS to draw attention to uses of the product that could result in
personal injuries, as well as the probable seriousness of those injuries. Other signal words call attention to
uses likely to cause property damage. Signal words used in this manual appear below along with the
definition of each word.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury
.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.
SAFETY INSTRUCTIONS
We strive to identify all hazards associated with the use of our products. However, material
handling is dangerous and no manual can address every risk. The most effective way to avoid injury
is for the end-user to exercise sound judgment whenever using this product.
Improper or careless operation of this drum dumper might result in serious personal injuries.
• Failure to read and understand the entire manual before assembling, using or servicing the
product constitutes misuse. Read the manual whenever necessary to refresh your understanding of
proper use and maintenance procedures.
• ONLY use the dumper as a means for emptying drums. ALWAYS properly load the dumper according
to the directions in Loading the Dumper on p. 11.
• DO NOT use a damaged dumper. Inspect the dumper according to the Inspection instructions on p.
11-12. DO NOT continue to use the dumper unless it is in Satisfactory Condition.
• DO NOT stand beneath or travel under the dumper chute while it is elevated.
• DO NOT load or operate the chute of a portable dumper unless both floor locks (part no. 08-025-008
in figures 5, 6, 7, and 8 on pages 7, 8, 9, and 10) solidly contact the floor. Floor locks are located on
either side of the handle. Wind the locks through the threaded receivers in the frame until they solidly
contact the ground.
• DO NOT use this dumper UNLESS every label shown in the Labeling Diagram on p. 24 is in place,
undamaged, and easily readable.
• DO NOT exceed the capacity of the dumper. The capacity of each model appears in the tables on pp.
2-3 as well as on label 287. See Labeling diagram on p. 24. The weight of the container to be dumped
plus the weight of its contents must not exceed the capacity.
• DO NOT modify the dumper in any way UNLESS you first obtain written approval from Vestil.
Modifying the dumper without first receiving approval automatically voids the Limited Warranty and might
make the dumper unsafe to use.
DO NOT fill the hydraulic system with brake fluid or jack oils. Only fill the hydraulic system
with either anti-wear hydraulic oil, viscosity grade 150 SUS at 100°F (ISO 32cSt at 40°C) or Dexron
transmission fluid.
APPLYING FLOOR LOCKS (HDD- ##-#-P units only)
A floor lock is provided on both sides of the handle. In Figures 5, 6, 7, and 8 on pages 7, 8, 9, and
10, floor locks are identified as part no. 08-025-008. Once the dumper is in the necessary position and
before loading the chute with a drum, wind the floor locks through the threaded receivers (welded to the
frame) until they solidly contact the floor. Do not turn the locks so far that the casters are noticeably
lifted off of the floor because the dumper might become unstable if 1 or more casters are lifted off of the
floor. It is only necessary for the locks to press against the floor. Try to push the dumper to confirm that
the locks are engaged. The dumper should resist movement although all 4 casters remain in contact
with the floor.
