TABLE OF CONTENTS Rev. 11/3/2021 FPG, MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Co. Page 8 of 11
USING THE CRANE
Before using the crane for the first time: 1) Perform a “Before & after each use” inspection (INSPECTIONS &
MAINTENANCE, part A, p. 22); and 2) Conduct a load test (INSPECTIONS & MAINTENANCE, part C, p. ).
WARNING
Operate the crane in a safe manner to reduce the risk of serious personal injuries or death.
• Only use this crane if you are qualified and trained to use it. The operating instructions in this manual
supplement safe crane and hoist operation practices applied at your work site. Acquire a copy of the most
recent edition of ASME B30.17 and apply all operation, inspection, maintenance, and care recommendations.
• ALWAYS apply the safe material handling practices learned from your training program.
• All personnel not participating in the use of the crane must stay out of the area during use. Be certain no part
of any person or object is under any part of the boom (I-beam) or the suspended load at any time and
particularly before lowering it. Instruct all persons to remain at a safe distance during operation.
• Always carefully watch the boom and any load hanging from it while using the crane.
• Always follow the hoist and trolley manufacturers’ instructions regarding proper use of their products.
• BEFORE the load is connected to the hoist, lock or immobilize the casters, for example with chocks.
• Only use this crane on level concrete (or equal) surface.
• DO NOT use the crane and notify your supervisor and authorized maintenance personnel if: 1) you observe any
damage or hear unusual noise during operation; or 2) you observe any warping or deformation of the I-beam,
the adjustable uprights, the load hook or hoist chain/cable.
• DO NOT operate a hoist with a twisted, kinked, or damaged chain or rope. DO NOT operate a rope hoist unless
the rope is properly seated in its groove.
NOTICE
This crane can be used outdoors but should be sheltered from the weather when not in use.
SIDE
VIEW
Front view
PROPER LOAD CENTERING
Hoist
!
Position the hoist directly above the load.
Center the hoist above the center of the load
(see SIDE VIEW) and position the long axis of
the I-beam above the center of the load (see
END VIEW). Proper positioning is illustrated in
the loading diagrams.
Apply all caster brakes by pressing brake
levers down. See STEP 2 on p. 7. Confirm that
the crane is immobilized.
Connect the load to the hoist chain/cable
with appropriate rigging following the
instructions supplied with your hoist and the
material handling methods applied at your
work site. Raise the load only as high as is
necessary. Once the load is properly
centered above the work location, lower the
load until it is fully supported by the ground or
work surface. and disconnect the load from
the hoist. Return the crane to its storage
locations.
If you must move the load to a different
location, return the load to the ground or
other supporting surface, e.g. pallet, and
disconnect it from the hoist. Move the crane
and load separately to the work location.
Only use the crane to lift loads.
END
VIEW
IMPROPER LOAD CENTERING
SIDE
VIEW
END
VIEW
