Table of Contents Rev. 9/25/2023 FMDL MANUAL
Table of Contents Copyright 2023 Vestil Manufacturing Co. Page 15 of 20
OPTIONAL EQUIPMENT
Cushioned drum cradles are available for FMDL-style drum lifters. Models FMDL-1-LDS-B1 and FMDL-2-
LDS-B1 include saddles equipped with rubber belts. FMDL-1-LDS-R3 and FMDL-2-LDS-R3 provide rollers
along the face of the drum saddle. Exploded views of cushioned models are provided on pages 15, 16,
and 17.
FMDL-1-LDS-B1 (40-006-101)
FMDL-2-LDS-B1 (40-006-102)
Item
Part no.
Description
Qty.
1
40-514-008
Weldment, frame
1
2
40-514-105
Frame, subassembly
1
3
99-112-004
Pin, self-locking, quick
release
1
4
09-145-018
Chain,
5
/
16
” x 56”
1
5
08-145-041
Snap hook,
5
/
16
”
1
6
33-112-023
Pin, clevis
1
7
65125
Cotter pin, z-plated,
3
/
16
”
x 1
1
/
2
”
1
*8
40-001-098
Saddle/bumper belt
assembly
1
* Bumper belt subassembly exploded view
provided on p. 14.
Item
Part no.
Description
Qty.
1
40-514-008
Weldment, frame
1
2
44-112-001
Pin, main, clevis
4
3
40-514-105
Frame, subassembly
2
4
40-516-008
Weldment, bracket,
mounting bar
1
5
65125
Cotter pin, z-plated,
3
/
16
” x 1
1
/
2
”
1
6
99-112-004
Pin, self-locking,
quick release
1
7
08-145-041
Snap hook,
5
/
16
”
1
8
09-145-018
Chain,
5
/
16
” x 56”
1
*9
40-001-098
Bumper belt
subassembly
1
* Bumper belt subassembly exploded view
provided on p. 14.
