Table of Contents Rev. 12/5/2023 FLB MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Company Page 4 of 7
NATIONAL STANDARDS
US OSHA Rule 1910.178 (29 CFR 1910.178; the “Rule”) classifies this device as a (lift truck) “front- end
attachment” whenever it is mounted on a lift truck. The Rule incorporates American National Standard
ANSI/ITSDF B56.1 (the “Standard”). The Standard is published by the Industrial Truck Standards Development
Foundation on its website (www.itsdf.org) where it is freely downloadable at http://www.itsdf.org/cue/b56-
standards.html. Before putting this device into service, you must acquire a copy of the Standard. Apply all
relevant parts of Part II: For the User. If instructions provided in this manual apparently conflict with the
Standard, then apply the instructions in the Standard. Vestil requests that you immediately share any
conflicts you discover with its TECHNICAL SERVICE personnel. Contact information for TECHNICAL SERVICE
appears on the cover page of this manual.
RECORD OF SATISFACTORY CONDITION (THE “RECORD”)
Record the condition of your lifting beam before putting it into service. Measure the length and width of
the lifting shackle. Include a measurement of the throat opening of the shackle, i.e. the area that receives
the shackle pin. Record your measurements. Measure the throat openings of both load hooks and record
your measurements. Thoroughly photograph the unit from multiple angles. Include close range photos of all
labeling, the lifting shackle and shackle pin, the fork channels, safety strap and hook, and the (X-handle)
locking bolts (08-025-004). Collate all photographs and writings into a single file. Mark the file appropriately
to identify it. The file provides a record of the device in satisfactory condition. Compare the results of all
INSPECTIONS (see p. 5) to this RECORD to determine whether the unit is in satisfactory condition. If the lifter is
not in satisfactory condition, repair it before returning it to service. Purely cosmetic changes, like damaged
paint/powdercoat, do not constitute changes from satisfactory condition. However, touchup paint should
be applied to all affected areas as soon as cosmetic damage occurs to prevent rusting and corrosion. If
left unaddressed, rusting/corrosion will alter the lifter from satisfactory condition and could make it unsafe to
use.
LOADING AND USING THE LIFTING BEAM
Periodically review the SAFETY INSTRUCTIONS on p. 2 and applicable content from the most recent
revision of ANSI B56.1.
NOTE: Before this product may be used, U.S. Occupational Safety and Health Administration rule
1910.178(a)(4) and (a)(5) require that the beam owner/user:
a. Obtain written approval from the manufacturer(s) of all forklifts that will use the beam [or from a
professional engineer];
b. Change capacity, operation, and maintenance instruction plates, tags, or decals accordingly; AND
c. Mark the forklift truck to identify the beam and show the approximate weight of the truck and beam
combination at maximum elevation with load laterally centered.
These requirements are published online at
https://www.osha.gov/pls/oshaweb/owadisp.show_document?p_table=STANDARDS&p_id=9828
Attach the Lifting Beam to the forks of your lift truck
1. Adjust the locations of the forks on the carriage to align with the fork slots in the beam. Center the forks
on the carriage. Tilt the mast slightly towards the cab.
2. Slide the beam onto the forks. Wind both locking bolts (part no. 08-025-004 in EXPLODED VIEW on p. 3)
clockwise until tension plates (part no. 08-037-037) solidly contact the undersides of the forks and the ends
of the locking bolts tightly press against the top sides of the forks. Confirm that the beam is securely
attached to the forks, for example by trying to slide the beam forward on the forks. The beam should not
be able to move.
3. Attach the safety strap (part no. 08-145-028) to the fork carriage without slack. Wrap the strap around a
part of the carriage and attach the hook to the strap. The safety strap is intended to prevent the beam
from sliding off of the forks. DO NOT use it as load rigging. Attach the hook at the end of the safety strap to
the carriage or the safety strap.
Loading the Beam
Capacity figures are provided on label 1000 in both pounds and kilograms. It indicates the net capacity
of the hook in pounds. See LABELING DIAGRAM on p. 6.
Connect the load to the FLB in a manner that minimizes load swing when it is lifted off of the ground.
Swinging loads might cause injuries and/or could damage equipment.
