Table of Contents Rev. 12/5/2023 FLB MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Company Page 2 of 7
SIGNAL WORDS
SIGNAL WORDS in this manual draw the reader’s attention to important safety-related messages.
SAFETY INSTRUCTIONS
Vestil strives to identify all foreseeable hazards associated with the use of its products, but no manual can
address every conceivable risk. Prevent injury by applying sound judgment whenever using this device.
Acquire a copy of the latest version of ITSDF/ANSI B56.1 (“B56.1” or the “Standard”). The Standard is freely
downloadable on www.ITSDF.org. Apply all portions of Part II “For the User” about the use of attachments and
removable attachments. The following instructions complement provisions of B56.1.
WARNING
Using this device might result in serious personal injuries or death. Acquire a copy of the latest version of
ANSI B56.1 (“B56.1” or the “Standard”). The Standard is freely downloadable on www.ITSDF.org. Apply all
portions of Part II “For the User” that pertain to the use of attachments and removable attachments. The
following recommendations are intended to complement the provisions of B56.1.
Inspect the lifting beam before each use by applying the relevant INSPECTION instructions on p. 5. DO
NOT use the beam unless it is in satisfactory condition.
DO NOT contact electrified wires with the lifter, load, or lift truck.
DO NOT use the beam unless it is securely attached to the carriage of your lift truck with the safety strap.
Attach the safety strap to the lift truck carriage without slack.
DO NOT use the lifting beam if the safety strap is damaged or missing. The purpose of the safety strap is to
prevent the lifter from sliding off of the forks. It is NOT intended or designed to bear the full load rating.
DO NOT attempt to lift loads that weigh more than the beam’s capacity/maximum rated load: 10,000
pounds (4,545.5kg).
DO NOT stand, or walk, under the forks, beam, or suspended loads.
Inform everyone in the area that you are going to use the lifting beam.
DO NOT allow people to ride on the forks or loads suspended from the lifter.
DO NOT use the beam if any label is damaged or missing, or not easily readable from a reasonable, safe
distance. See LABELING DIAGRAM on p. 6.
Always make sure that threaded shackle pin (part no. 08-145-006 in the EXPLODED VIEW on page 3) is
secure before applying a load to the shackle. Tighten the shackle pin before each use.
Before attaching a load to the beam, slightly tilt the fork lift mast towards the cab to prevent the beam
from sliding towards the tips of the forks.
ALWAYS follow the LOADING AND USING THE LIFTING BEAM instructions that appear on p. 4-5. Failure to
properly position a load might cause a dangerous degree of load swing when the beam is elevated.
Only use the beam to lift loads. DO NOT use the beam to pull or drag loads.
DO NOT transport people with the beam or allow people to ride on load items.
Transport loads with the load as close to the ground as possible. Drive at slowly when a load is applied
and brake and turn slowly and cautiously.
DO NOT modify the beam in any way UNLESS you first obtain written approval from Vestil. Unapproved
modifications automatically void the LIMITED WARRANTY (p. 7) and might make the beam unsafe to use.
Whenever the beam is mounted on the forks of a lift truck, apply BOTH fork locking bolts (part no. 08-025-
004 in the EXPLODED VIEW on p. 3) AND attach the safety strap to the fork carriage without slack.
Carefully lift loads just a few inches above the ground. Confirm that the load is stable. Loads must not
rotate, swing, roll, etc. DO NOT attempt to transport unstable loads. Return the load to the ground and
adjust rigging as necessary to stabilize the load.
DO NOT lift more than 1 item at a time.
DO NOT leave suspended loads unattended. Move the load to its desired location, set it down, and
disengage it from the beam.
DANGER
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
WARNING
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
NOTICE
Identifies practices likely to result in product/property damage, such as operation
that might damage the product.
!
!
!
