Table of Contents Rev. 8/21/2020 FL-4000 MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Corp. Page 6 of 8
RECORD OF SATISFACTORY CONDITION (THE “RECORD”)
Before using this loader for the first time, create a record OF its appearance and features. Include
descriptions of the chute, feet, base, carriage chain and quick link, pivot points and pivot point hardware, and the
chute release mechanism. Release the chute. Describe how the unit looks and sounds as the chute rotates. Also
describe the force necessary to release the chute using both the manual release lever and the cable (release the
chute 2 times). Secure the chute to the base and describe how the latch mechanism works. Thoroughly
photograph the unit including all labels. Collate all writings and photographs into a single file. This file is a record
of the unit in satisfactory condition. Compare your results of all inspections to this record to determine if the
unit is still in satisfactory condition. Restore the loader to satisfactory condition BEFORE using it again. Purely
cosmetic changes, like damaged surface coating (paint or powdercoat) are not changes from satisfactory
condition. However, touchup paint should be applied as soon as damage occurs to prevent rusting.
INSPECTIONS & MAINTENANCE
Inspections and repairs should only be performed by qualified persons. Compare the results of each inspection
to the RECORD. Do not use the loader unless all parts are in satisfactory condition. Replace parts that are not in
satisfactory condition before using the loader again. DON’T GUESS! If you have any questions about the
condition of your loader, speak with TECHNICAL SERVICE personnel. The phone number is provided on the
cover page of this manual. Never make temporary repairs of damaged or missing parts. Only use
manufacturer-approved replacement parts.
Inspections
Make a dated record of the inspection that includes all observations and described repairs and/or
replacements made.
1) Pivot points: Look for excessive wear, bends, or other significant damage to hinge/pivot pins, cotter pins, and
pin receivers.
2) Chute and base frame: Examine the structures for damage, deformation, corroded or excessively rusted
regions. Remove rust and apply touch-up paint to exposed metal.
3) Hardware (bolts, nuts, pins, cotter pins, retaining rings): Inspect hardware for looseness and severe wear.
Tighten loose connections. Replace all damaged hardware.
4) Release mechanism [see STEP 3 on p. 5]: The torsion spring should cause the latch lever to automatically
recoil. The lever should firmly contact the lock bar. Check the release cable for frayed, thinned, or cut regions.
5) Moving parts: Listen for unusual noises and watch for irregular movement while releasing and re-latching the
chute. Remove dirt and debris from areas that could affect the loader’s dumping motion.
6) Safety chain: Examine the safety chain. Also examine its point of attachment to the base frame.
7) Labels: Labels must be firmly affixed in the locations shown in the LABELING DIAGRAM on p. 7.
Maintenance
Implement a maintenance program to ensure that the product functions properly and is adequately maintained.
The following steps should be applied to complement established maintenance programs.
Step 1: Tag the loader, “Out of Service.”
Step 2: Inspect the unit as described on p. 5. DO NOT continue to use the product if repairs/replacements are
needed.
Step 3: Perform all necessary adjustments, replacements, and repairs.
Step 4: Make a dated record of all repairs.
