TABLE OF CONTENTS 5/19/2022 EPT MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Page 4 of 58
REMOVE THE EPT FROM THE SHIPPING PALLET
The pallet truck is shipped in ready-to-use condition. However, it must first be removed from the shipping
pallet before it can be used for the first time.
DO NOT attempt to drive the pallet truck off of the pallet; it might tip over and cause bodily injuries
or property damage. To minimize the risk of injury to yourself or other persons, perform the following steps to
remove the machine from the shipping pallet:
1. Remove all packing material.
2. Inform all personnel not participating in the unpacking process to clear the area.
3. Lift the EPT off of the pallet using either a hoist or a forklift with a capacity of at least 2,000 pounds. Always
apply the proper hoisting procedures or forklift operation practices you learned during your training program.
Extract the EPT from the shipping pallet (with overhead hoist):
EPT-2###-45 models: Remove the battery box.
a) Disconnect the power cable from the socket on top of the EPT housing (circled in photo 1 below). Unfasten the
box from the EPT frame by unscrewing the bolt in the center of the flange; the bolt is shown in photograph 2 (next
page).
b) Connect the sling to both hook points on the EPT (1 on each side; the picture below only shows the hook point
on the right side); then lift the unit no more than 6 – 8 inches above the pallet. The EPT will tilt towards the
control yoke. Additionally, it may swing from side-to-side once free of the pallet if you did not properly position the
hoist above the center of the sling. Stabilize the suspended truck with one hand, and stand safely to the side while
operating the hoist.
All Models: Securely connect the sling hooks to the hook points (see photographs below), lift the EPT a few
inches off of the pallet, direct the EPT away from the pallet, and then lower it until it is entirely supported by the
ground.
To lift the EPT with a forklift:
Avoid contacting the drive wheel with the tines of your
forklift; contact could damage the drive wheel.
Approach the pallet truck from the operator side. Lift the EPT just a few
inches above the pallet. Slowly back the forklift away from the pallet, and
then carefully lower the forks until the EPT rests firmly on the ground.
Operator
Side
Loading
side
Hook point
1
2
3
