Rev. 0213 EPT, Manual.doc
Copyright 2013 Vestil Manufacturing Corp. Page 14 of 51
Item No. Part No. Description
3101 EPT-30-SCL- M6 x 12 Bolt
3102 EPT-30-SCL- Handle Cover (Bottom)
3103 EPT-30-SCL- Throttle Seat
3103-2 EPT-30-SCL- Belly / Horn Switch
3104 EPT-30-SCL- Electrical Outlet (Large)
3105 EPT-30-SCL- Electrical Outlet (Small)
3106 EPT-30-SCL- Throttle Knob (left)
3107 EPT-30-SCL- Handle Cover (Top)
3108 EPT-30-SCL- Spring
3109 EPT-30-SCL- Horn Switch Operator
3110 EPT-30-SCL- Raise / Lower Button
3111 EPT-30-SCL- Throttle Knob
3112 EPT-30-SCL- M3 x 10 Screw
3113 EPT-30-SCL- Throttle Shaft Bushing
3114 EPT-30-SCL-
Emergency Stop / Reverse Switch Cover (Red)
3114-2 EPT-30-SCL- Switch Cover Spring
3115 EPT-30-SCL- Throttle
3116 EPT-30-SCL- Yoke Arm
3117 EPT-30-SCL- M8 x 10 Bolt
3118 EPT-30-SCL- 8mm Spring Washer
3119 EPT-30-SCL- Gas Shock
3120 EPT-30-SCL- Handle Limit Switch
3121 EPT-30-SCL- M4 x 30 Screw
3122 EPT-30-SCL- M4 Nut
3123 EPT-30-SCL- M5 x 6 Screw
3124 EPT-30-SCL- Yoke Arm Access Panel
3201 EPT-30-SCL- 20mm Washer
3202 EPT-30-SCL- Pivot Pin
3203 EPT-30-SCL- 16 x 20 Sleeve Bearing
3204 EPT-30-SCL- Handle Coupling
3205 EPT-30-SCL- M8 x 30 Bolt
3206 EPT-30-SCL- 8mm Spring Washer
3207 EPT-30-SCL- Rubber Boot, Coupler Cover
3208 EPT-30-SCL- M56 x 1.5 Nut
3209 EPT-30-SCL- Washer 56
3210 EPT-30-SCL- Flat Washer
3211 EPT-30-SCL- M10 x 40 Bolt
3212 EPT-30-SCL- 10mm Spring Washer
3213 EPT-30-SCL- M8 x 1 Grease Zerk
3214 EPT-30-SCL- Bearing Housing
3215 EPT-30-SCL- Bearing 8112
3216 EPT-30-SCL- Ball Bearing 80113
3217 EPT-30-SCL- Steering Post
3218 EPT-30-SCL- M10 x 30 Bolt
3219 EPT-30-SCL- 10mm Flat Washer
3300 EPT-30-SCL- Drive Wheel Assembly
