TABLE OF CONTENTS 5/19/2022 EPT MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Page 14 of 58
FIG.
5B BILL OF MATERIALS
Item No.
Part No.
Description
3101
EPT-30-SCL-
M6 x 12 Bolt
3102
EPT-30-SCL-
Handle Cover (Bottom)
3103
EPT-30-SCL-
Throttle Seat
3103-2
EPT-30-SCL-
Belly / Horn Switch
3104
EPT-30-SCL-
Electrical Outlet (Large)
3105
EPT-30-SCL-
Electrical Outlet (Small)
3106
EPT-30-SCL-
Throttle Knob (left)
3107
EPT-30-SCL-
Handle Cover (Top)
3108
EPT-30-SCL-
Spring
3109
EPT-30-SCL-
Horn Switch Operator
3110
EPT-30-SCL-
Raise / Lower Button
3111
EPT-30-SCL-
Throttle Knob
3112
EPT-30-SCL-
M3 x 10 Screw
3113
EPT-30-SCL-
Throttle Shaft Bushing
3114
EPT-30-SCL-
Emergency Stop / Reverse Switch Cover (Red)
3114-2
EPT-30-SCL-
Switch Cover Spring
3115
EPT-30-SCL-
Throttle
3116
EPT-30-SCL-
Yoke Arm
3117
EPT-30-SCL-
M8 x 10 Bolt
3118
EPT-30-SCL-
8mm Spring Washer
3119
EPT-30-SCL-
Gas Shock
3120
EPT-30-SCL-
Handle Limit Switch
3121
EPT-30-SCL-
M4 x 30 Screw
3122
EPT-30-SCL-
M4 Nut
3123
EPT-30-SCL-
M5 x 6 Screw
3124
EPT-30-SCL-
Yoke Arm Access Panel
3201
EPT-30-SCL-
20mm Washer
3202
EPT-30-SCL-
Pivot Pin
3203
EPT-30-SCL-
16 x 20 Sleeve Bearing
3204
EPT-30-SCL-
Handle Coupling
3205
EPT-30-SCL-
M8 x 30 Bolt
3206
EPT-30-SCL-
8mm Spring Washer
3207
EPT-30-SCL-
Rubber Boot, Coupler Cover
3208
EPT-30-SCL-
M56 x 1.5 Nut
3209
EPT-30-SCL-
Washer 56
3210
EPT-30-SCL-
Flat Washer
3211
EPT-30-SCL-
M10 x 40 Bolt
3212
EPT-30-SCL-
10mm Spring Washer
3213
EPT-30-SCL-
M8 x 1 Grease Zerk
3214
EPT-30-SCL-
Bearing Housing
3215
EPT-30-SCL-
Bearing 8112
3216
EPT-30-SCL-
Ball Bearing 80113
3217
EPT-30-SCL-
Steering Post
3218
EPT-30-SCL-
M10 x 30 Bolt
3219
EPT-30-SCL-
10mm Flat Washer
3300
EPT-30-SCL-
Drive Wheel Assembly
