Je bekijkt pagina 12 van 58
TABLE OF CONTENTS 5/19/2022 EPT MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Page 12 of 58
FIG.
5A BILL OF MATERIALS
Item No.
Part Number
Description
3100
EPT-30-3100-2
Control Handle
3101
EPT-30-3101
Screw
3102
EPT-30-3102
Handle Cover (Bottom)
3103
EPT-30-3103
Throttle Seat with Switches
3103-2
EPT-30-3103-2
Belly / Horn Switch
3104
EPT-30-3104
Electrical Outlet (Big)
3105
EPT-30-3105
Electrical Outlet (Small)
3106
EPT-30-3106
Throttle Knob (Left)
3107
EPT-30-3107
Top Handle Cover (grey)
3108
EPT-30-3108
Spring – (Same as EPT-30-3114-2)
3109
EPT-30-3109
Horn Switch Operator
3110
EPT-30-3110
Raise / Lower Button with Micro-Switch
3111
EPT-30-3111
Throttle Knob (right)
3112
EPT-30-3112
M3 x 10 Screw
3113
EPT-30-3113
Throttle Shaft Bushing
3114
EPT-30-3114
Emergency Reverse Switch Cover
3114-2
EPT-30-3114-2
Emergency Reverse Return Spring
3115
EPT-30-3115
Throttle Assembly (identical to EPT-45-1112)
3115
EPT-30-3115-2
Throttle Assembly Unit
3115
EPT-30-3115-3
Curtis Throttle Assembly
3116
EPT-30-3116
Yoke Arm
3116-2
EPT-30-3116-2
Upper Removable Cover
3117
EPT-30-3117
Bolt
3118
EPT-30-3118
8mm Washer
3119
EPT-30-3119
Gas Shock
3201
EPT-30-3201
Snap Ring 20mm
3202
EPT-30-3202
Pivot Pin
3203
EPT-30-3203
Bushing
3204
EPT-30-3204
Handle Coupling (identical to EPT-45-1210)
3205
EPT-30-3205
Hex Head Cap Screw
3206
EPT-30-3206
8mm Washer
3207
EPT-30-3207
Rubber Coupling Cover (same as EPT-45-1210)
3208
EPT-30-3208
M56 x 1.5 Nut
3209
EPT-30-3209
56mm Washer
3210
EPT-30-3210
Washer
3211
EPT-30-3211
Bolt
3212
EPT-30-3212
Washer
3213
EPT-30-3213
Grease Zerk
3214
EPT-30-3214
Bearing Housing
3215
EPT-30-3215
Bearing 8112
3216
EPT-30-3216
Bearing 80113
3217
EPT-30-3217
Steering Post
3218
EPT-30-3218
M10 x 30 Bolt
3219
EPT-30-3219
10mm Washer
3220
EPT-30-3220
Handle Limit Switch
3300
EPT-30-3300
Drive Wheel System
