8/1/2016 EPFC-25.docx
Copyright 2016 Vestil Manufacturing Corp. Page 5 of 7
Specifications
Model
EPFC-25
Capacity
2,500 / 1,300 / 600 lbs
Lift Height
45¼ - 130”
Lift
Speed
Loaded
1/2”/sec
Unloaded
0.70”/sec
Lower
Speed
Loaded
¾”/sec
Unloaded
¼”/sec
Travel
Speed
Loaded
2.18 mph
Unloaded
2.8 mph
Drive Motor
24V/700W
Lift Motor
DC24V/2.0KW
Battery
2x12V/70-80Ah
Battery Charger
24V/12A
Gradeability
0%
Overall size
79½x30x66⅜”
Maintenance
Before working on the unit, turn off power, lower the boom, and confirm that the brakes are engaged working properly.
Chock the wheels to secure the truck. Disconnect batteries before working on the electrical system.
1. Check electrical wiring for frays, etc. Inspect the batteries for leaks and accumulated corrosion.
2. Battery electrolyte level should be checked before charging the battery. The level should be maintained at 1/2 inch
above the plates. Do not overfill. Charge the battery at the end of each day's usage.
The battery should be charged at least once per week when not in use.
3. Before checking the hydraulic fluid level, park the truck on a level surface and fully lower the boom.
Remove the filler cap and check the level of the fluid. Check the hydraulic hoses for significant wear, kinks, cuts, etc.
Replace damaged hoses. Change the oil at least once a year. The oil should be changed as soon as it darkens,
becomes gritty, or appears milky. Milky appearance indicates the presence of water. Replace the oil with AW-32
hydraulic fluid or its equivalent.
Trouble Shooting
If a malfunction occurs while performing any of the following tests, do not use it until the truck is restored to
normal operating condition. The table below identifies several common issues and provides lists of possible
causes. To resolve other issues, contact technical support at Vestil.
1. Verify the battery cable connections are tight on the batteries.
2. Verify there is no leakage of oil from previous use.
3. Pull the red button, item 2.3, up and check the battery charge indicator.
4. Test boom functions: rise, lower, extend and retract.
5. Test drive functions (forward and reverse).
