ASSEMBLY INSTRUCTIONS
NOTE: During the assembly procedure, bolts & nuts should be hand-tightened. Once
assembly is complete, bolts and nuts must be fully tightened.
1. Attach two 1 ½” x Ø4 swivel casters (#6) to base frame using nuts (#9),
lock washers (#10) & washer (#11).
2. Referring to the spare parts drawing, insert two legs (#G) into the base (#F)
and secure the legs in place using 2 set screws (#12).
3. Attach the main support post (#C) to the base assembly (#F) using bolts
(#8), flat washers (#11) and nuts (#9).
4. Now secure the boom (#B) to the main support post (#C) using bolt (#17),
flat washer (#22) and nut (#14).
5. Attach support brackets (#D) to top of the main support post using bolt
(#8), flat washers (#11) and nut (#9).
6. Attach support brackets (#D) to the frame base using bolts (#8), flat
washers (#11), spring washers (10) and nuts (#9).
7. Connect bottom of cylinder (#E) to main support post (#C) using bolt (#13),
flat washer (#22) and nut (#14).
8. Hold the boom up with the help of a helper, connect top of the cylinder (#E)
to boom using bolt (#15), flat washer (#21) and nut (#16).
9. Slide boom extension (#A) into the main boom (#B), secure in one of the
four positions using lock pin (#19).
10. Tighten all the bolts, lock washers & nuts.
