TABLE OF CONTENTS Rev. 6/5/2024 EHLTD MANUAL
TABLE OF CONTENTS Copyright 2024 Vestil Manufacturing Co. Page 9 of 35
ITEM
PART NO.
DESCRIPTION
QTY.
1
02-002-210
FINAL ASSEMBLY W/O POWER UNIT (NO DECK)
1
2
01-145-006
SHAFT COLLAR, 1PC SPLIT, Ø1 1/8"
2
3
02-513-028
WELDMENT, DECK (SUB) 1-4K 38 x 54
1
4
02-513-029
WELDMENT, DECK, ASS'Y 1-4K
1
5
02-527-002
ROLLER ASS'Y W/ BUSHING 2 OD x 1 1/8" ID
2
6
02-540-007
WELDMENT, LEVER ASSMEBLY
1
7
02-540-008
WELDMENT, LEVER ASSMEBLY
1
8
02-612-011
PIN, DECK LINK Ø1 1/8 x 7 3/16 LG
2
9
04-612-011
WELDMENT, PIN W/RETAINING BRKT
4
10
99-021-929-001
CYLINDER, HYDRAULIC, Ø2" x 6" PISTON STYLE W/ CLEVIS
MOUNTS (RIGHT HAND PORT)
1
11
99-021-930-001
CYLINDER, HYDRAULIC, Ø2" x 6" PISTON STYLE W/ CLEVIS
MOUNTS (LEFT HAND PORT)
1
12
99-145-036
Ø 1/4" CHAIN 60"
1
13
99-145-069
1/4" CHAIN HOOK
1
14
33454
NARROW MACHINERY BUSHING, PLAIN FINISH, 1 3/4" X 18 GA
12
15
45286
#11 HITCH PIN CLIP, Ø1/8" X 2 5/8 LG
4
16
68021
EXTERNAL RETAINING RING, PHOSPHATE FINISH, 1-1/8"
4
17
01-022-001
LIMIT SWITCH W/ROLLER ARM
1
18
01-515-044
SUB-ASSEMBLY, TOE GUARD, 38" X 54", INCLUDES HARDWARE
& SWITCHES
1
BILL OF MATERIALS: EHLTTS-3654-2-48 (02-006-211-001)
