TABLE OF CONTENTS Rev. 6/5/2024 EHLTD MANUAL
TABLE OF CONTENTS Copyright 2024 Vestil Manufacturing Co. Page 7 of 35
BILL OF MATERIALS: EHLTD-4848-1/2/3/4-70 (26-006-111-002)
ITEM
PART NO.
DESCRIPTION
QTY.
1
24-002-050
24-002-110
FINAL ASSEMBLY W/O POWER UNIT (NO DECK)
EHLTT-4848-1/2/3-47
EHLTT-4848-4-47
1
1
1.1
01-514-007
WELDMENT, FRAME ASSEMBLY
1
1.2
24-510-008
24-510-011
WELDMENT, LEG, OUTER
EHLTT-4848-1/2/3-47: SINGLE CYL.
EHLTT-4848-4-47: DOUBLE CYLINDER
1
1
1.3
01-527-001
ROLLER W/ BUSHING
4
1.4
68021
EXTERNAL RETAINING RING, PHOSPHATE FINISH, 1-1/8"
12
1.5
24-510-014
WELDMENT, LEG, INNER, SINGLE CYL
1
1.6
01-112-004
PIN, CLEVIS
4
1.7
33454
NARROW MACHINERY BUSHING, PLAIN FINISH, 1 3/4" X 18 GA
8
1.8
01-112-019
PIN, SCISSOR PIVOT, Ø1 1/2"
2
1.9
33474
SPACER, SHIM, 1 1/2" ID X 2 1/4 OD X 18 GA
2
1.1
99-521-901-002
99-521-906-001
CYLINDER, HYDRAULIC
EHLTT-4848-1/2/3-47: Ø3" x 10" RAM STYLE, MACHINED END, 3GPM VF
EHLTT-4848-4-47: 2.5” X 10” RAM STYLE, MAHCINED END, 2GPM VF
1
2
1.11
24-612-003
WELDMENT, CYLINDER PIN
1
1.12
01-118-001
BOLT, CYLINDER RETAINING
1
1.13
24-037-001
MAIN PROP, EHLT
2
1.14
33444
MACHINE BUSHING, Ø 1 X 18 GA.
2
1.15
20-117-003
EXTERNAL RETAINING RING, 1" DIA SHAFT
2
1.16
26333
SHOULDER SCREW, GRADE 2, 0.375x1.5" LG
2
1.17
33006
FLAT WASHER,ZINC PLATED,USS, Ø5/16"
2
1.18
37021
NYLON INSERT LOCK NUT, GRADE 2, ZINC FINISH, 5/16"-18
2
1.19
36209
1/2 - 13 HEX JAM NUT PLAIN, GRADE A
1
1.2
32415
Ø5/16 - 18 x 1/2 HWH THREAD CUTTING SCREW, TYPE F, ZINC
1
1.21
01-115-002
WASHER, THRUST BEARING
2
1.22
01-115-001
WASHER, THRUST BEARING, 1 1/8 ID
8
2
02-513-058
02-513-060
WELDMENT, DECK 48W x 48 LG
EHLTT-4848-1/2/3-47
EHLTT-4848-4-47
1
1
3
02-513-054
02-513-056
WELDMENT, SUB-DECK
EHLTT-4848-1/2/2-47: 1-3K, 36" WIDE, BOLT-ON
EHLTT-4848-4-47: 4K, 36” WIDE, BOLT-ON
1
1
4
20-117-003
EXTERNAL RETAINING RING, 1" DIA SHAFT
6
5
99-021-923-001
CYLINDER, HYDRAULIC, Ø3" x 16" PISTON STYLE, W/ CLEVIS MOUNTS
1
6
02-527-002
ROLLER ASS'Y W/ BUSHING 2 OD x 1 1/8" ID
2
7
33454
NARROW MACHINERY BUSHING, PLAIN FINISH, 1 3/4" X 18 GA
12
8
02-540-003
WELDMENT, LEVER, LINKTILT LINKAGE
1
9
02-540-006
WELDMENT, LEVER, LINK TILT LINKAGE, WITH LIMIT SWITCH BKT
1
10
03-612-002
HINGE PIN ASS'Y (EM)
2
11
33446
MACHINERY BUSHING, PLAIN FINISH, Ø1" ID x 10 GA.
2
12
99-029-011
CONTROL BOX
1
13
01-022-001
LIMIT SWITCH W/ROLLER ARM
2
14
27560
#10-32 x 3/4 LG SLOTTED MACHINE SCREW
2
15
36030
10-32 HEX NUT, GRADE 2
2
16
01-515-015
SUB-ASSEMBLY, TOE GUARD, 36" X 48", INCLUDES HARDWARE
& SWITCHES
1
