Operator’s Manual 10/23/2023 EHLT-TL MANUAL
Table of Contents Copyright 2023 Vestil Manufacturing Co. Page 16 of 22
WARNING
Unsafe use could result in serious personal injuries or death.
DO NOT exceed the lift table’s load ratings. Injury to personnel or permanent damage to the lift table can result
from exceeding the listed capacity. Note: Take into account the weight of any equipment added to the platform by
third parties when determining the maximum working load to be placed on the platform.
The platform rollers are not captured. DO NOT overhang any load over the side of the platform. A cantilevered or
overhanging load at the hinged end can cause the platform to tilt and dump the load. For applications involving
side or end edge loading, consult the factory.
This lift table is not designed, intended, or approved, for lifting personnel.
Keep all personnel clear of the machine when it is in operation. Before operating the lift table, make certain no
part of any person or object is under the platform.
Guards shall be in place before operating the lift table.
Guards cannot protect against every possible condition, and should not be considered a substitute for good
judgment and care in use, loading, handling, storage, etc. of the lift table.
Operation.
At the beginning of every shift, inspect the perimeter toe guard for correct operation. First raise the platform.
Push and hold a section of the perimeter toe guard up against the platform. The platform should not move when the
“LOWER” button is pressed. Perform this check on all four sides of the platform.
Check the condition of the guards, controls, scissors mechanisms, hydraulic lines, and limit switches. If any item is
in need of repair or otherwise contributes to an unsafe condition, remove the lift table from service until it has been
restored to a safe operating condition.
The standard EHLT-TL scissor lift table is furnished with an internally-mounted electric-hydraulic power unit and a
handheld pushbutton control.
Press the “RAISE” pushbutton to energize the power unit and raise the
platform. The platform will rise only while the pushbutton is pressed.
When the pushbutton is released, the platform will stop and hold its
position. At the platform’s maximum height, a limit switch prevents the
platform from further rising.
Press the “LOWER” pushbutton to open the hydraulic valve and lower the
platform. The platform descends by gravity, and the pump motor will not
run. Release the pushbutton to stop the motion of the platform. If the
perimeter toe guard encounters an object, the valve will close and prevent
further descent of the platform.
The EHLT-LT lift table is provided with hydraulic overload protection that
will prevent it from raising a load in excess of its rated capacity. The
lowering speed is preset at the factory, and will not exceed a speed of 30 fpm. In the event of a hydraulic line
failure, a velocity fuse (internal to each cylinder) closes and prevents the platform from lowering.
CAUTION
Always watch the area around the platform and any load on the platform when it is in operation.
Never use the lift table if any damage or unusual noise is observed, if it is in need of repair, or if any other
malfunction is observed. Notify your supervisor or maintenance personnel.
INSPECTION AND MAINTENANCE
Proper maintenance is essential for maximizing the service life of this product. If an inspection reveals any
irregularities in the lift table’s condition, repair it before returning it to service. Only use manufacturer-approved
replacement parts. Contact Technical Service if you have questions that are not addressed in these instructions or
