TABLE OF CONTENTS Rev. 11/28/2022 EHLT-E MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Co. Page 4 of 17
BILL OF MATERIALS: EHLT-E (01-006-525)
ITEM
PART NO.
DESCRIPTION
QTY.
1
01-002-525 FINAL ASSEMBLY W/O POWER UNIT 1
1.1
01-514-204
WELDMENT, FRAME
1
1.2
01-513-029 WELDMENT, DECK 1
1.3
01-510-100
WELDMENT, LEG, SCISSOR, OUTER
1
1.4
01-510-097 WELDMENT, LEG, SCISSOR, INNER 1
1.5
01-527-002
ROLLER, ASSY Ø2 1/4" X 1/2" W
4
1.6
38-117-001 RETAINER RING, EXTERNAL FOR Ø3/4 SHAFT 4
1.7
01-113-001
SPACER/SHIM (MCH BUSHING)
12
1.8
01-112-008 PIN, SCISSOR PIVOT 2
1.9
64134
SPRING PIN
2
1.1
33456 MACHINERY BUSHING, PLAIN FINISH, Ø1 1/8" X 10 GA 2
1.1
24-037-001
MAIN PROP, EHLT
1
1.1
33444 MACHINE BUSHING, Ø 1 X 18 GA. 1
1.1
20-117-003
EXTERNAL RETAINING RING, 1" DIA SHAFT
1
1.1 99-021-906-001
CYLINDER, HYDRAULIC, Ø2 1/2" X 10" RAM STYLE,
MACHINED END
1
1.2 01-612-004
SUB-ASSEMBLY, CLEVIS PIN WITH RETAINING RING
GROOVE
4
1.2
01-612-003 SUB-ASSEMBLY, CLEVIS PIN W/ RETAINING RING GROOVE 1
2
01-022-001
LIMIT SWITCH W/ROLLER ARM
1
3
24-016-002 BRACKET, EHLT SWITCH MOUNT 1
4 99-660-171
POWER UNIT, SUB-ASSEMBLY, 208-230/460V AC, 3 PH,
1.4HP, 1725 RPM, 0.122 DISP, 1.0 GPM FLOW CONTROL, L-
H-L, w .6 GAL. L-SHAPE TANK & FITTINGS, INTERNAL POWER
1
4.1 99-160-277
POWER UNIT, SUB-ASSEMBLY, 208-230/460V AC, 3 PH, 1.4
HP, 1725 RPM, 0.122 DISP, 1.0 GPM FLOW CONTROL, L-H-L
w/ .6 GAL, L-SHAPE TANK
1
4.2
99-529-200-001 SUB-ASSEMBLY, CONTROL, BOX, 7" X 4" X 3", NEMA 1
4.3 99-533-017
ASSEMBLY, CORD, STRAIGHT, 18/5, 30" MOLDED FEMALE
RECEPTACLE, 5-PIN
1
4.4 99-522-035
ASSEMBLY, HAND CONTROL (2-BUTTON), CORD, COILED,
18/3, 18"-90", 48" TAIL, 3-PIN MOLDED MALE PLUG
1
4.5
99-033-073 CONNECTOR, COIL, COMMON, CUT TO 34" 1
5
36104
HEX NUT, GRADE A, ZINC PLATED, 5/16-18
4
