TABLE OF CONTENTS 5/12/2022 EH MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Page 6 of 19
Power Unit Exploded View and Bill of Materials
EH-610, EH-75, EH-76, EH-78, & EH-710
Item
Part no.
Description
Qty.
1 06-627-004
Subassembly, Manifold, Lift-Lower, Double Acting LIP (detail view on
p. 7)
1
2
99-137-033-003
99-137-033-004
99-137-013-002
99-137-008-001
99-137-008-002
Motor-and-Pump subassembly:
208-230V AC, 3-phase, 2HP, 3450rpm, 0.180 displacement
460V AC, 3-phase, 2HP, 3450rpm, 0.180 displacement
208-230V AC, 1-phase, 2HP, 3450rpm, 0.122 displacement
115V AC, 1-phase, 0.75HP, 1725rpm, 0.073 displacement
208-230V AC, 1-phase, 0.75HP, 1725rpm, 0.073 displacement
1
1
1
1
1
3
99-116-001
Suction fitting, mini-manifold
1
4
33687
Lock washer, high collar,
5
/
16
”
4
5
23255
5
/
16
”-18 x 1” socket head cap screw
4
6
06-023-003
Hydraulic tank
1
7
99-145-061
Clamp, worm gear hose, 2
13
/
16
” – 3
3
/
4
”
1
8
99-144-007
O-ring, manifold, 3” outer diameter
1
9
99-031-029
Accessories, hydraulic
1
10
01-116-003
Breather,
1
/
2
” NPT
1
11
99-144-009
O-ring, manifold,
3
/
4
” outer diameter
1
12
99-144-008
O-ring, manifold,
1
/
2
” outer diameter
1
13
99-031-033
Accessories, nipple, close pipe
1
Return to Page 4
