TABLE OF CONTENTS 5/12/2022 EH MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Page 1 of 19
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
www.vestil.com info@vestil.com
EH-Series Dock Levelers
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of
it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can
also be contacted online at https://www.vestil.com/page-parts-request.php
.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php.
TABLE OF CONTENTS
PAGE
Signal Words…………………………………………………………………………………………………………...…
2
Safety Instructions………………………………………………………………………………………...…………….
2
EH-65, EH-66, EH-68 and EH-610 Exploded View & Bill of Materials…………………………………………....
3
EH-75, EH-76, EH-78 and EH-710 Exploded View & Bill of Materials………………………………………..…..
4
Power Unit Exploded View and Bill of Materials [EH-65; EH-66; & EH-68]……………………………………..
5
Power Unit Exploded View and Bill of Materials [EH-610; EH-75; EH-76; EH-78; & EH-710]…………………
6
Manifold Exploded View and Bill of Materials [EH-65; EH-66; & EH-68]……………………………………….
7
Manifold Exploded View and Bill of Materials [EH-610; EH-75; EH-76; EH-78; & EH-710]…………………...
7
Electrical Circuit Diagram, 115V AC, 1-Phase..………………………………….………………………….…….
8
Electrical Circuit Diagram, 208-230V AC, 1-Phase……………………………....…………………………..……
9
Electrical Circuit Diagram, 208V, 230V, & 460V, 3-Phase AC………………………………….………….……
10
Electrical System Operation..…………………………………………………………………………….…………..
11
Hydraulic Circuit Sequence of Operation………………………………….…………………………………..….
11
Adjusting Hydraulic Settings…………………………………….………………………………………………........
12
Installation………………………………………………………………………………………………………………..
13
Operating the Dock Leveler………………..………………………………………………………………………...
13, 14, 15
Record of Satisfactory Condition……………………………………………………………………………………
15
Troubleshooting………………..……………...…………………………………………………………………..........
16
Inspections and Maintenance……………..……………………………...……………………………………..….
17 - 18
Labeling Diagram………..….………………………………..……………………………………………..………….
18
Limited Warranty…………………………………………………………………………………………………….….
19
