Table of Contents Rev. 9/25/2023 FMDL MANUAL
Table of Contents Copyright 2023 Vestil Manufacturing Co. Page 13 of 20
B. Periodic Inspections: At least once every 2 weeks inspect the carrier to confirm satisfactory condition.
Do not return it to service unless it is in satisfactory condition.
1. Fasteners (hardware) and hand chain: Examine all bolts, nuts, washers, pins, the quick link, and snap
hooks. Tighten loose fasteners. Replace locking fasteners with new fasteners
2. Fork pockets: Confirm that each pocket is structurally sound. In particular, examine the underside of
the each pocket for rust and corrosion.
3. Welds: Make sure that all welds are intact. Check welds & the metal surrounding welds for damage.
4. Gripper arms and hinge castings: Confirm that both arms and hinge castings are not cracked or
warped. Hinge castings should rotate smoothly to allow the arms to fold onto the frame for compact
storage.
5. Safety strap, quick link, and hook (attached to the free end of the safety chain): Confirm that the
quick link is undamaged and welded securely to the frame. The snap hook should not be bent,
stretched, cracked, or otherwise damaged. Check the strap for cuts, tears, etc. If your unit is
equipped with a safety chain instead of a strap, check the chain links for breaks, cracks, bends,
elongations, etc.
6. Pivot points/ hinges: Confirm that gripper arms pivot normally and/or that hinges operate normally.
Check pivot points and hinges for significant wear. Lubricate the hinges. Lubrication might have to
be applied more frequently under heavy usage conditions.
7. Frame: The structure should be clean, square and rigid, and free of rust and corrosion. Clean the
frame. Examine it for severe wear, rust, and other forms of damage.
MAINTENANCE
Step 1: Tag the unit “Out of Service.”
Step 2: Remove any dirt or other matter from all surfaces.
Step 3: Conduct a “Periodic” inspection. If deformity, corrosion, rusting, or excessive wear of structural
members is found, permanently remove the unit from service.
Step 4: Perform all necessary adjustments, replacements and/or repairs but DO NOT modify the carrier.
DO NOT use the unit if adjustments and/or repairs are incomplete!
An “adjustment” is a simple correction that restores the unit to satisfactory condition, such as tightening
loose fasteners, or removing dirt or other debris from the surface. “Repair” refers to removing worn parts
and installing manufacturer-approved replacement parts.
A “modification” is a change that alters the drum carrier from satisfactory condition, like bending the
structural members or removing a part or several parts. NEVER modify the unit without the express, written
approval of Vestil. Modifications might make the device unsafe to use and automatically void the LIMITED
WARRANTY.
Step 5: Make a dated record of all repairs, adjustments and/or replacements.
