Step 6: Return the chute to the latched position. Tilt the forklift mast toward the cab and back away from the
dumpster. The hopper should automatically return to the latched position. Confirm that the chute is latched to the base
by tilting the mast forward (away from the cab). The chute should not dump. If the chute will not latch by tilting the
mast backwards, set the hopper on the ground and manually latch the chute to the frame. Press down on the rear wall
of the chute until the latch lever engages the latch bar. Apply the lock.
RECORD OF SATISFACTORY CONDITION
After receiving the unit and before using it for the first time, create a record that describes the appearance
and operation of the hopper. Thoroughly photograph the unit from multiple angles. Take close range
photographs of the labels, release mechanisms, safety chain—particularly at each end, pivot points, and
pivot point hardware. Mount the hopper of the forks of your forklift and apply the safety chain. Elevate the
hopper and release the chute. Record your observations about how the unit looks and sounds as the chute
rotates. Lower the unit and secure the chute to the frame. Record your observations. This written record
establishes satisfactory condition. Compare the results of all inspections to this record to determine whether
a component is in satisfactory condition or requires repair or replacement. If issues are discovered during an
inspection, DO NOT use the hopper until it is restored to satisfactory condition. Purely cosmetic changes,
like damaged surface coating (paint or powdercoat) are not changes from satisfactory condition. However,
touchup paint should be applied wherever the finish is damaged as soon as damage occurs.
INSPECTIONS & MAINTENANCE
Inspections and repairs should only be performed by qualified persons. Compare the results of each
inspection to the RECORD OF SATISFACTORY CONDITION (the “RECORD”). Do not use the hopper
unless all parts are in satisfactory condition. Replace parts that are not in satisfactory condition before using
the hopper again. DON’T GUESS! If you have any questions about the condition of your hopper,
speak with TECHNICAL SERVICE personnel. The phone number is provided on the cover page of this
manual. Never make temporary repairs of damaged or missing parts. Only use manufacturer-approved
replacement parts.
Step 1: At least once per month, tag the hopper “Out of Service.”
Step 2: Inspect the hopper. Replace any component that is not in satisfactory condition.
1.) Pivot points: Check for excessive wear, warping, or other significant damage to pivot pins, cotter pins,
and pin receivers.
2.) Hopper chute and base frame: Examine the structures for damage, deformation, and corroded or
excessively rusted regions. Remove rust with a steel bristle brush and apply touch-up paint to exposed
metal.
3.) Hardware (bolts, nuts, pins, cotter pins, retaining rings): Inspect hardware for looseness and severe
wear. Tighten loose connections and replace all damaged hardware.
4.) Casters (if hopper is equipped with caster kit): Check for looseness, excessive wear, and damage to
the caster wheels, caster bearings, mounting brackets, and mounting hardware.
5.) Release mechanism: The torsion spring should cause the latch lever to automatically recoil and the
lever should firmly contact the release lock bar. Check the release cable for frays, thinning, corrosion,
and bird-caging.
6.) Pivot points: Listen for unusual sounds. Watch for irregular movements. Remove dirt and debris from
areas that could affect the dumping motion.
7.) Carriage chain: Examine the chain, the attachment to the base frame, and the quick links for damage.
8.) Labels: All labels should be present in the locations shown in the Labeling Diagram on p. 17.
Step 3: Perform all adjustments, replacements, and repairs necessary to restore satisfactory condition.
DO NOT modify the hopper in any way without first obtaining written approval from Vestil.
Modifications automatically void the Limited Warranty and might make the hopper unsafe to use. A
modification is a change that alters the hopper, like or removing or bending a component.
Step 4: Make a dated record of all repairs and replacements.
