Table of Contents Rev. 6/17/2024 D MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 3 of 18
D-250-HD
2½ yd
3
(1.91 m
3
)
6,000 lb.
(2,727.3 kg)
69
9
/
16
” x 68
3
/
8
” x 51
3
/
4
”
(176.7 x 173.7 x 131.4)cm
28”
(71.1cm)
863 lb.
392.3 kg
D-300-HD
3 yd
3
(2.29 m
3
)
6,000 lb.
(2,727.3 kg)
81
3
/
4
” x 68
5
/
8
” x 51
13
/
16
”
(207.6 x 174.3 x 131.6)cm
28”
(71.1cm)
940 lb.
427.3 kg
D-300-HD-NA
3 yd
3
(2.29 m
3
)
6,000 lb.
(2,727.3 kg)
55
5
/
16
” x 79
3
/
8
” x 64
3
/
8
”
(140.5 x 201.6 x 163.5)cm
28 in.
(71.1cm)
1115 lb.
506.8 kg
D-350-HD
3½ yd
3
(2.69 m
3
)
6,000 lb.
(2,727.3 kg)
64” x 79
3
/
8
” x 64
3
/
8
”
(162.6 x 201.6 x 163.5)cm
28 in.
(71.1cm)
1169 lb.
531.4 kg
D-400-HD
4 yd
3
(3.08 m
3
)
6,000 lb.
(2,727.3 kg)
72
11
/
16
” x 79
3
/
8
” x 64
3
/
8
”
(184.6 x 201.6 x 163.5)cm
28 in.
(71.1cm)
1224 lb.
556.4 kg
D-500-HD
5 yd
3
(3.85 m
3
)
6,000 lb.
(2,727.3 kg)
90” x 79
3
/
8
” x 64
3
/
8
”
(228.6 x 201.6 x 163.5)cm
28 in.
(71.1cm)
1332 lb.
605.5 kg
Options
Model
Description
Net Weight
LEKP
“Leak proof” welded hopper
5 lb. (2.3kg)
D-DPLG-75
3/4in. drain plug option
2 lb. (0.9kg)
D-DPLG-2
2in. drain plug option
2 lb. (0.9kg)
LUG
4 welded lifting lugs (around perimeter of hopper mouth)
23 lb. (10.5kg)
D-PIN
Steel fork retaining pin (tine lock)
5 lb. (2.3kg)
D-TILT
Sideways chute dumping configuration; D-75-LD and D-100-LD models
only
130 lb. (59.1kg)
Heavy-duty polyethylene lids
Lid Model
Parts
Description
Fits Hopper Models
Net Weight
PLID-D-25
37-024-087-002
37-112-028
37-016-034
37-016-033
Plastic lid
Prop rod / hinge pin
Bracket, Lid hinge, right
Bracket, lid hinge, left
D-25-LD, D-25-MD, D-25-HD
16 lb. (7.3kg)
PLID-D-33
37-024-087-002
37-112-028
37-016-034
37-016-033
Plastic lid
Prop rod / hinge pin
Bracket, Lid hinge, right
Bracket, lid hinge, left
D-33-LD, D-33-MD, D-33-HD
16 lb. (7.3kg)
PLID-D-50
37-024-087-001
37-112-029
37-016-034
37-016-033
Plastic lid
Prop rod / hinge pin
Bracket, Lid hinge, right
Bracket, lid hinge, left
D-50-LD, D-50-MD, D-50-HD
21 lb. (9.5kg)
PLID-D-75
37-024-086-002
37-112-030
37-016-034
37-016-033
Plastic lid
Prop rod / hinge pin
Bracket, Lid hinge, right
Bracket, lid hinge, left
D-75-LD, D-75-MD, D-75-HD
22 lb. (10kg)
PLID-D-100
37-024-086-001
37-112-031
37-016-034
37-016-033
Plastic lid
Prop rod / hinge pin
Bracket, Lid hinge, right
Bracket, lid hinge, left
D-100-LD, D-100-MD, D-100-HD
28 lb. (12.7kg)
PLID-D-150
37-024-085-004
37-112-032
37-016-034
37-016-033
Plastic lid
Prop rod / hinge pin
Bracket, Lid hinge, right
Bracket, lid hinge, left
D-150-LD, D-150-MD, D-150-HD
33 lb. (15kg)
PLID-D-200
37-024-089
37-112-033
37-016-034
37-016-033
Plastic lid
Prop rod / hinge pin
Bracket, Lid hinge, right
Bracket, lid hinge, left
D-200-LD, D-200-MD, D-200-HD
58 lb. (26.4kg)
PLID-D-250
37-024-085-002
37-112-034
37-016-034
37-016-033
Plastic lid
Prop rod / hinge pin
Bracket, Lid hinge, right
Bracket, lid hinge, left
D-250-LD, D-250-MD, D-250-HD
51 lb. (23.2kg)
PLID-D-300
37-024-085-001
37-112-035
37-016-034
37-016-033
Plastic lid
Prop rod / hinge pin
Bracket, Lid hinge, right
Bracket, lid hinge, left
D-300-LD, D-300-MD, D-300-HD
61 lb. (27.7kg)
