Table of Contents Rev. 3/20/2023 D MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 14 of 18
SIGNAL WORDS
SIGNAL WORDS in this manual draw the reader’s attention to important safety-related messages.
SAFETY INSTRUCTIONS
Vestil strives to identify all foreseeable hazards associated with the use of its products, but no manual
can address every conceivable risk. Prevent injury by applying sound judgment whenever using this
device. Acquire a copy of the latest version of ANSI B56.1 (“B56.1” or the “Standard”). The Standard is
freely downloadable on www.ITSDF.org. Apply all portions of Part II “For the User” that concern the use
of attachments and removable attachments. The following instructions complement provisions of B56.1.
WARNING
Risk of serious personal injuries or death! Always apply the following safety instructions.
Before this product may be used, U.S. Occupational Safety and Health Administration rule
1910.178(a)(4) and (a)(5) require that the owner/user: 1) Obtain written approval from the
manufacturer(s) of all forklifts [or from a professional engineer] that will use the hopper; 2) Change
capacity, operation, and maintenance instruction plates, tags, or decals accordingly; AND 3) Mark the
forklift truck to identify the beam and show the approximate weight of the truck and beam
combination at maximum elevation with load laterally centered. Requirements are published at
https://www.osha.gov/pls/oshaweb/owadisp.show_document?p_table=STANDARDS&p_id=9828
Read & understand this entire manual before using or servicing the hopper.
Inspect the hopper as directed in the INSPECTIONS & MAINTENANCE section on p. 16. DO NOT use it
unless it is in SATISFACTORY CONDITION. See RECORD OF SATISFACTORY CONDITION on p. 16.
DO NOT use the hopper if the carriage chain is damaged or missing; DO NOT lift the hopper until it is
securely connected to the carriage of the fork truck with the carriage chain. ONLY use this hopper with
a powered forklift truck. DO NOT mount the hopper on stackers or manually propelled lift trucks.
DO NOT fill the hopper beyond its maximum rated load. See SPECIFICATIONS tables on page 2.
NO ONE should travel under the hopper at any time while it is elevated.
NEVER wrap the release cable around your hand, fingers, or any other part of your body!
Hoppers with lifting lugs can be lifted with overhead hoists and cranes. DO NOT lift a hopper unless the
chute is securely latched to the frame.
DO NOT allow people to ride on or in the hopper.
DO NOT use the hopper if any label is unreadable or missing. Apply replacement labels before
returning the hopper to service. See LABELING DIAGRAM on p. 17.
ALWAYS apply proper lift truck operation techniques learned during your training program. Before
raising the hopper from the floor, tilt the (forklift) mast toward the cab of the truck to ensure that the
hopper will not slide off of the forks.
DO NOT modify the hopper without first obtaining written approval from Vestil! Unapproved
modifications might make the hopper unsafe & automatically void the LIMITED WARRANTY on p. 12.
DO NOT dump the hopper UNLESS every person in the vicinity is a safe distance away from the
dumping site.
DO NOT dump the hopper unless the forklift is on an even, level surface.
DO NOT exceed the load ratings or fill the hopper above the side walls. Injury to personnel or
permanent damage to the equipment could result from overloading.
NOTE: Because this product is self-dumping, it helps to prevent non-compliance with US Federal OSHA
rule 1910.178(m)(5). In particular, subpart 1910.178(m)(5)(iii), requires operators of powered trucks to fully
lower the “load engaging means” (forks), neutralize truck controls, and set brakes whenever they
dismount a lift truck and remain within 25ft of it. This product allows lift truck operators to remain at the
controls of their trucks throughout the dumping process.
DANGER
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
WARNING
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
NOTICE
Identifies practices likely to result in product/property damage, such as operation
that might damage the product.
!
!
!
!
