Operator’s Manual 4/16/21 CTD-H-TP-3000 MANUAL.DOCX
Table of Contents Copyright 2021, Vestil Manufacturing Corp. Page 6 of 14
Item
Part No.
Description
Qty.
Item
Part No.
Description
Qty.
1
15-514-142
WELDMENT, FRAME LOWER
1
20
45286
#11 HITCH PIN CLIP,
Ø1/8" X 2 5/8 LG
2
2
15-514-145
WELDMENT, FRAME UPPER
1
21
99-116-042
FITTING, HYDRAULIC,
06MORB HOLLOW HEX
PLUG
1
3
15-514-146
WELDMENT, TOP STOP
1
22
99-112-004
PIN, SELF LOCKING QUICK
RELEASE, GENERAL
2
4
11110
HEX BOLT, GRADE A, ZINC
FINISH, 3/8"-16 X 1 3/4"
2
23
15-514-147
WELDMENT, KICK
CYLINDER POSTIONER
1
5
20-110-006
ROLLER BEARING
2
24
99-021-915-
001
CYLINDER, HYDRAULIC,
Ø1 1/2" x 7", RAM STYLE
1
6
21-113-021
SPACER, BEARING SHAFT
2
25
03-146-001
SPRING, LEVER
1
7
33008
FLAT WASHER, LOW CARBON,
USS, ZINC PLATED, 3/8"
2
26
28-112-031
Ø3/4 x 4 1/2 LG CLEVIS
PIN
1
8
37024
NYLON INSERT LOCK NUT,
GRADE 2, ZINC FINISH, 3/8"-16
2
27
65080
EXTENDED PRONG
COTTER PIN, ZINC FINISH,
1/8" x 2"
1
9
68083
E-CLIP,STEEL,FOR Ø5/8" SHAFT
2
28
37030
1/2"-13 NYLON INSERT
LOCK NUT
1
10
15-145-016
GAS CYLINDER, LEVER
POSITIONER
2
29
33011
FLAT WASHER, USS,
PLAIN FINISH, Ø1/2"
2
11
15-112-073
PIN, CYLINDER PIVOT
2
30
99-112-006
PIN, CLEVIS
1
12
99-116-096
FITTING, HYDRAULIC, 06MJ-
08MORB STRAIGHT
7
31
65076
Ø1/8" X 1" COTTER PIN,
Z-PLATED
1
13
06-116-001
FITTING, HYDRAULIC, HOSE,
04G-06FJX STRAIGHT
7
32
15-021-038
CYLINDER, HYDRAULIC, 2
X 20, DIA, W/ HARD LINE
2
14
15-612-003
WELDMENT, PIN, FRONT
4
33
25326
SOCKET SET SCREW,
BLACK OXIDE,
1/4-20 X 1/4"
4
15
99-116-028
FITTING, HYDRAULIC, HOSE,
04G-06FJX 90° ELBOW
2
34
08-145-041
SPECIALTY HARDWARE,
SNAP HOOK, Ø5/16
1
16
15-112-074
PIN, FRONT STOP POSITION
INDICATOR, FORMED
2
35
09-145-018
CHAIN, 5/16" x 56" LG
1
17
65124
COTTER PIN Z PLATED,
3/16 x 1 1/4
2
36
91253A581
5/16"-18 x 3/4" HEX
DRIVE SOCKET CAP
SCREW BLACK OXIDE
4
18
36266
Ø3/4 - 16, HEX JAM NUT, ZINC
PLATED
2
37
15-034-028
ACCESSORIES,
ELECTRICAL, SHRINK
WRAP
4
19
14-612-001
PIN, LOCK, WELDMENT
2
38
15-145-018
SPECIALTY HARDWARE,
CAP
2
