Exploded View, Bill of Materials, and Specifications: COLA-5-##-## Models
44-006-650
Item
Part no.
Description
Qty.
Item
Part no.
Description
Qty.
1
44-513-026
44-513-027
44-513-028
44-513-029
Weldment, deck, platform:
COLA-5-56-20; COLA-5-68-20
COLA-5-56-32; COLA-5-68-32
COLA-5-56-44; COLA-5-68-44
COLA-5-56-56; COLA-5-68-56
1
1
1
1
6
44-024-288
44-024-289
44-024-290
44-024-291
Guard, middle handrail:
COLA-5-56-20; COLA-5-68-20
COLA-5-56-32; COLA-5-68-20
COLA-5-56-44; COLA-5-68-44
COLA-5-56-56; COLA-5-68-56
2
2
2
2
2
44-514-216
44-514-216
44-514-217
44-514-217
Weldment, frame, steps
(stairway):
COLA-5-56-20; COLA-5-56-32
COLA-5-56-44; COLA-5-56-56
COLA-5-68-20; COLA-5-68-32
COLA-5-68-44; COLA-5-68-56
2
2
2
2
7
44-524-063
44-524-063
44-524-069
44-524-069
Weldment, guard, lower handrail:
COLA-5-56-20; COLA-5-56-32;
COLA-5-56-44; COLA-5-56-56
COLA-5-68-20; COLA-5-68-32
COLA-5-68-44; COLA-5-68-56
4
4
4
4
8
11209
Bolt, HHCS, ASTM A307, gr. A, z-
plated,
1
/
2
”-13 x 1
1
/
2
”
4
3
44-524-184
44-524-184
44-524-185
44-524-185
Weldment, guard, upper handrail:
COLA-5-56-20; COLA-5-56-32
COLA-5-56-44; COLA-5-56-56
COLA-5-68-20; COLA-5-68-32
COLA-5-68-44; COLA-5-68-56
4
4
4
4
9
33012
Flat washer, low carbon, z-finish,
1
/
2
”
8
10
37030
Lock nut, Nylon insert,
1
/
2
”-13
4
11
11205 Hex bolt, gr. A, z-plated,
1
/
2
”-13x1” 12
4
44-516-016
Assembly, handrail, pipe end
8
12
33625
Lock washer, medium split, plain,
1
/
2
”
12
5
44-024-292
44-024-293
44-024-294
44-024-295
44-024-296
44-024-297
44-024-298
44-024-299
Guard, top handrail:
COLA-5-56-20
COLA-5-56-32
COLA-5-56-44
COLA-5-56-56
COLA-5-68-20
COLA-5-68-20
COLA-5-68-44
COLA-5-68-56
2
2
2
2
2
2
2
2
13
33011
Flat washer, USS, plain,
1
/
2
”
12
14
11105
Hex bolt, gr. A, z-plated,
3
/
8
”-16x1”
8
15
37024
Nylon insert lock nut, gr. 2, z-finish,
3
/
8
”-16
8
16
44-024-118
44-024-118
44-024-125
44-024-125
Guard, bumper, adhesive backed:
COLA-5-56-20; COLA-5-56-32
COLA-5-56-44; COLA-5-56-56
COLA-5-68-20; COLA-5-68-32
COLA-5-68-44; COLA-5-68-56
2
2
2
2
