Table of Contents Rev. 3.17.2021 TCD MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 19 of 20
Labeling diagrams
The unit should be labeled as shown in the diagram. However, label content and location are subject to change
so your product might not be labeled exactly as shown. Replace all labels that are damaged, missing, or not easily
readable (e.g. faded). Order replacement labels by contacting the Parts Department online at
http://www.vestilmfg.com/parts_info.htm. Alternatively, you may request replacement parts and/or service by calling
(260) 665-7586 and asking the operator to connect you to the Parts Department.
D: Label 287 (on nosing of a step)
C: Label 220 (applied to both side guards)
A: Label 725 (applied to both sides of chute)
B: Label 212 (on frame)
A
C
D
B
A
D
B
C
Modular Power Unit (MPU):
The labels shown below are applied to original/first generation power units. Trash dumpers built after 12/01/19
receive 2
nd
generation modular power units (MPU-GEN2). There are separate manuals for MPU-GEN2 power units.
These manuals include labeling diagrams. If you purchased a trash dumper on or after 12/01/18, then you should
receive an MPU-GEN2 instruction manual. Refer to the Labeling Diagram in that manual.
Label 295 (front and
back of MPU)
Label 206 (close to or on oil reservoir)
[AC Units only] Label 248 , 249, 250, or
251 (electrical system specifications)
248 = 115VAC, 1-phae
249 = 208-230VAC, 3-phase
250 = 460VAC, 3-phase
251 = 208-230VAC, 1-phase
