TABLE OF CONTENTS Rev. 4/13/2023 CBB-3000-37 MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Co. Page 8 of 19
CBB-3000-37 BILL OF MATERIALS (22-006-023)
ITEM
PART NO.
DESCRIPTION
QTY.
ITEM
PART NO.
DESCRIPTION
QTY.
1
22-002-023
FINAL ASSEMBLY W/O POWER UNIT
1
1.4
22-537-003
WELDMENT, DYNAMIC STOP
3
1.1
22-514-066
WELDMENT, EJECT HOOK
2
1.41
22-514-065
WELDMENT, COUNTERWEIGHT
2
1.2
22805
ELEVATOR BOLT, GRADE A, LIMIT
SWITCH
1
1.42
22-612-005
WELDMENT, PIN, HINGE
2
1.3
37018
NYLON LOCK NUT,GRADE 2, ZINC
FINISH,1/4"-20
15
1.43
A-PJ-6079-A1
XXXX
1
1.4
65127
COTTER PIN Z PLATED, 3/16 x 2
4
1.43.1
A-6079-A-A
1
1.5
22-612-008
WELDMENT, PIN, HINGE
2
1.43.1.1
A-PJ-6079-P-C
XXXX
1
1.6
22-537-005
WELDMENT, LOCK, DOOR, ANGLE
1
1.43.1.1.1
A-PJ-6079-P-E
1
1.7
22-145-012
SPECIALTY HARDWARE,
HANDWHEEL TURNBUCKLE
1
1.43.1.1.2
A-PJ-6079-P-F
1
1.8
22-113-021
SPACER
6
1.43.1.1.3
A-PJ-6079-P-G
1
1.9
99-116-126
FITTING, HYDRAULIC, 16MJ-
16MAORB 90° ELBOW
1
1.43.1.1.4
A-PJ-6079-A3
1
1.1
37030
1/2"-13 NYLON INSERT LOCK NUT,
GRADE 2
9
1.43.1.1.5
A-PJ-6079-P-D
1
1.11
33012
FLAT WASHER, LOW CARBON, ZINC
FINISH, 1/2"
9
1.43.1.2
A-PJ-6079-P-H
XXXX
1
1.12
24226
1/4"-20 X 1 1/4" FLAT HEAD SOCKET
CAP SCREW
16
1.43.1.2.1
A-PJ-6079-P-L
1
1.13
22-145-009
CHAIN, GATE
2
1.43.1.2.2
A-PJ-6079-P-K
1
1.14
22-145-010
CHAIN, BALE EJECT
2
1.43.1.2.3
A-PJ-6079P-M
2
1.15
11005
BOLT, GRADE A, Ø1/4-20 UNC x 1
LG, HHCS #2 Z-PLATED
8
1.43.1.2.4
A-PJ-6079-P-I
1
1.16
37039
NYLOCK NUT Z PLATED, GRADE 2,
Ø3/4 - 10
12
1.43.1.2.5
A-PJ-6079-P-J
1
1.17
45282
#6 HITCH PIN CLIP
1
1.43.1.3
A-PJ-6079-P-B
1
1.18
11209
1/2-13 X 1 1/2" LG HHCS - ASTM
A307 GRADE A, ZINC PLATED
9
1.43.1.4
A-PJ-6079-P-A
3
1.19
11003
HEX BOLT, GRADE A, ZINC PLATED,
1/4-20 X 3/4"
2
1.43.2
A-PJ-6079-A6
XXXX
1
1.2
11009
HEX BOLT, GRADE A, ZINC PLATED,
1/4"-20 X 1-1/2"
2
1.43.2.1
A-PJ-6079-P-P
1
1.21
20-042-033
SPROCKET, IDLER ASSEMBLY
2
1.43.2.2
A-PJ-6079-A4
XXXX
1
1.22
68013
Ø5/8 EXTERNAL RETAINING RING
2
1.43.2.2.1
A-PJ-6079-P-Q
1
1.23
01-111-073
BUSHING, DU, 1 1/8 ID X 3/4 LG
16
1.43.2.2.2
A-PJ-6079-P-S
1
1.24
01-115-001
WASHER, THRUST BEARING, 1 1/8 ID
4
1.43.2.2.3
A-PJ-6079-P-R
1
1.25
22-113-020
SPACER, NYLON STRIP
8
1.43.2.2.4
A-PJ-6079-P-T
2
1.26
11010
HEX BOLT, GRADE A, ZINC PLATED,
1/4"-20 x 1 3/4"
3
1.43.2.3
A-PJ-6079-A5
XXXX
1
1.27
21-145-008
SPECIALTY HARDWARE, EYEBOLT
2
1.43.2.3.1
A-PJ-6079-P-N
1
1.28
33076
#12, SAE FLAT WASHER, ZINC FINISH
2
1.43.2.3.2
A-PJ-6079-P-O
1
1.29
36102
HEX NUT, GRADE A, ZINC PLATED,
1/4-20
4
1.44
13371
HEX BOLT, GRADE 5, ZINC
FINISH, 3/4"-10 X 4-1/2"
4
1.3
37021
NYLON INSERT LOCK NUT, GRADE 2,
ZINC FINISH, 5/16"-18
4
1.45
13363
3/4-10 x 2 1/2 HHCS #5 Z
PLATED, GRADE 5
8
1.31
22-514-068
SUBASSEMBLY, SAFETY CABLE
1
1.46
33018
USS FLAT WASHER, Z PLATED, Ø
3/4"
8
1.32
22-612-006
WELDMENT, PIN, CYLINDER
1
1.47
S2200071-P1
BEARING, SLIDE
4
1.33
22-514-061
WELDMENT, FRAME
1
2
22-660-002
SUB-ASSEMBLY, REMOTE
POWER UNIT, 208-230/460V
AC, 3PH, 6.5 HP, 1750 RPM,
.97/.499 DISP., DA, PLC
1
1.34
22-514-063
WELDMENT, MAIN DOOR
1
3
99-029-190
ELECTRICAL ENCLOSURE, 16" X
14" X 6", MACHINED
1
1.35
22-513-001
WELDMENT, CRUSH PLATE
1
4
37024
NYLON INSERT LOCK NUT,
GRADE 2, ZINC FINISH, 3/8"-16
4
1.36
22-514-062
WELDMENT, FRAME, TOP
1
5
33008
FLAT WASHER, LOW CARBON,
USS, ZINC PLATED, 3/8"
4
1.37
22-514-064
WELDMENT, FRAME, GATE
1
6
11107
HEX BOLT, GRADE A, ZINC
FINISH, 3/8"-16 x 1-1/4"
4
1.38
22-516-007
WELDMENT, PULLEY, RIGHT
1
7
22-022-001
SENSOR, PROXIMITY SWITCH
2
1.39
22-516-008
WELDMENT, PULLY, LEFT
1
8
34-022-001
MAGNETIC POWER UP,
ASSEMBLY
1
*Shown in detail in POWER UNIT EXPLODED VIEW on p. 9.
