Page 7 of 15
CART-1100-SS bill of materials
Item No.
Part No. Description Item No. Part No. Description
101 C-1100-SS-101 Deck (of table) 227 C-1100-SS-227 Bushing
102 C-1100-SS-102 Bolt 228 C-1100-SS-228 Grease Nipple
103 C-1100-SS-103 Stainless Washer 229 C-1100-SS-229 Pedal Link
104 C-1100-SS-104 Arm Pin 230 C-1100-SS-230 Plunger Piston
105 C-1100-SS-105 Cylinder Pin 231 C-1100-SS-231 Spring Cap
106 C-1100-SS-106 Stainless Washer 232 C-1100-SS-232 Return Spring
107 C-1100-SS-107 Bolt 233 C-1100-SS-233 Pedal Pin
108 C-1100-SS-108 Cap Nut 234 C-1100-SS-234 Stainless Washer
109 C-1100-SS-109 Stainless Washer 235 C-1100-SS-235 Nut
110 C-1100-SS-110 Washer
Inlet & Outlet Check Valve Assembly
111 C-1100-SS-111 Scissor Pivot Shaft 236 C-1100-SS-236 Steel Bearing
112 C-1100-SS-112 Bushing 237 C-1100-SS-237 Spring
113 C-1100-SS-113 Bushing 238 C-1100-SS-238 Washer
114 C-1100-SS-114 Bushing 239 C-1100-SS-239 Valve Plug
115 C-1100-SS-115 Snap Ring 240 C-1100-SS-240 Elbow
116 C-1100-SS-116 Roller (bearing)
Relief Valve Assembly
117 C-1100-SS-117 Outer Scissor Arm 241 C-1100-SS-241 Steel Bearing
118 C-1100-SS-118 Roller Bearing Shaft 242 C-1100-SS-242 Spring Guide
119 C-1100-SS-119 Snap ring 243 C-1100-SS-243 Spring
120 C-1100-SS-120 Roller (bearing) 244 C-1100-SS-244 O-Ring
245 C-1100-SS-245 Adjustment Screw
201 C-1100-SS-201 Dust Seal 246 C-1100-SS-246 Nut
202 C-1100-SS-202 Backup Ring
Release Valve Assembly
203 C-1100-SS-203 O-Ring 206 C-1100-SS-206 O-Ring
204 C-1100-SS-204 O-Ring 247 C-1100-SS-247 Steel Bearing
205 C-1100-SS-205 Backup Ring 248 C-1100-SS-248 Release Valve Stem
206 C-1100-SS-206 O-Ring
207 C-1100-SS-207 Bushing 249 C-1100-SS-249 Roll Pin
208 C-1100-SS-208 Bushing
209 C-1100-SS-209 Piston Rod 250 C-1100-SS-250 Fill Plug O-Ring
Velocity Fuse Assembly
251 C-1100-SS-251 Oil Fill Plug
210 C-1100-SS-210 Nipple 252 C-1100-SS-252 Pressure Release Shaft
211 C-1100-SS-211 Valve Plug 253 C-1100-SS-253 Socket Bolt
212 C-1100-SS-212 Washer 254 C-1100-SS-254 Shaft Retaining Bushing
213 C-1100-SS-213 Spring 255 C-1100-SS-255 Guide
214 C-1100-SS-214 Spool 256 C-1100-SS-256 Nut
215 C-1100-SS-215 Spring 257 C-1100-SS-257 Release Knob
216 C-1100-SS-216 Valve Base 258 C-1100-SS-258 Handle
217 C-1100-SS-217 Nipple
218 C-1100-SS-218 Hose 301 C-1100-SS-301 Socket Bolt
302 C-1100-SS-302 Bolt
219 C-1100-SS-219 Spring Pin 303 C-1100-SS-303 Arm Pin
220 C-1100-SS-220 Plunger Roller 304 C-1100-SS-304 Stainless Washer
221 C-1100-SS-221 Spring Pin 305 C-1100-SS-305 Bolt
222 C-1100-SS-222 Pedal Boss 306 C-1100-SS-306 Frame
223 C-1100-SS-223 Pedal Boss Pin 307 C-1100-SS-307 Locking Caster
224 C-1100-SS-224 Socket Bolt 308 C-1100-SS-308 Swivel Caster
225 C-1100-SS-225 Pedal Cover 309 C-1100-SS-309 Rigid Caster
226 C-1100-SS-226 Pedal 310 C-1100-SS-310 Bolt
Replacement Parts Kits:
901 C-1100-SS-901 Seal Kit
941 C-1100-SS-941 Cylinder Assembly
942 C-1100-SS-942 Pump Assembly
