Page 5 of 15
CART-550-SS bill of materials
Item No. Part No. Description Item No. Part No. Description
101 C-500-SS-101 Table Deck 227 C-500-SS-227 Washer
102 C-500-SS-102 Arm Pin 228 C-500-SS-228 Nut
103 C-500-SS-103 Washer
Inlet & Outlet Check Valves
104 C-500-SS-104 Bolt 229 C-500-SS-229 Steel Ball
105 C-500-SS-105 Cylinder Pin 230 C-500-SS-230 Spring
106 C-500-SS-106 Washer 231 C-500-SS-231 Washer
107 C-500-SS-107 Bolt 232 C-500-SS-232 Threaded Cavity Plug
108 C-500-SS-108 Cap Nut 233 C-500-SS-233 Elbow
109 C-500-SS-109 Washer
Relief Valve Assembly
110 C-500-SS-110 Washer 234 C-500-SS-234 Steel Ball
111 C-500-SS-111 Scissor Pivot Shaft 235 C-500-SS-235 Relief Spring Guide
112 C-500-SS-112 Bushing 236 C-500-SS-236 Relief Spring
113 C-500-SS-113 Bushing 237 C-500-SS-237 O-Ring
114 C-500-SS-114 Bushing 238 C-500-SS-238 Adjustment Screw
115 C-500-SS-115 Snap Ring 239 C-500-SS-239 Nut
116 C-500-SS-116 Roller (bearing)
Release Valve Mechanism
117 C-500-SS-117 Outer Scissor Arm 206 C-500-SS-206 O-Ring
118 C-500-SS-118 Roller Bearing Shaft 240 C-500-SS-240 ¼ inch Steel Ball
119 C-500-SS-119 Snap Ring 241 C-500-SS-241 Release Valve Stem
120 C-500-SS-120 Roller (bearing) 242 C-500-SS-242 Roll Pin
201 C-500-SS-201 Dust Seal 243 C-500-SS-243 Oil Fill Plug O-Ring
202 C-500-SS-202 Backup Ring 244 C-500-SS-244 Oil Reservoir Fill Plug
203 C-500-SS-203 O-Ring 245 C-500-SS-245 Release Valve Shaft
204 C-500-SS-204 O-Ring 246 C-500-SS-246 Bushing Retaining Bolt
205 C-500-SS-205 Backup Ring 247 C-500-SS-247 Shaft Retaining Bushing
206 C-500-SS-206 O-Ring 248 C-500-SS-248 Guide
207 C-500-SS-207 Bushing 249 C-500-SS-249 Nut
208 C-500-SS-208 Bushing 250 C-500-SS-250 Release Knob
209 C-500-SS-209 Piston Ring 251 C-500-SS-251 Handle
211 C-500-SS-211 Hose
Velocity Fuse Assembly
212 C-500-SS-212 Spring Pin 252 C-500-SS-252 Adjustment Screw + Nut
213 C-500-SS-213 Plunger Roller 253 C-500-SS-253 Washer
214 C-500-SS-214 Spring Pin 254 C-500-SS-254 Spring
215 C-500-SS-215 Pedal Boss 255 C-500-SS-255 Safety Velocity Spool
216 C-500-SS-216 Pedal Boss Pin 256 C-500-SS-256 Spring
217 C-500-SS-217 Socket Bolt 257 C-500-SS-257 Valve Base
218 C-500-SS-218 Pedal Cover 258 C-500-SS-258 Nipple
219 C-500-SS-219 Pedal shaft 259 C-500-SS-259 Elbow
220 C-500-SS-220 Bushing
221 C-500-SS-221 Grease Nipple 301 C-500-SS-301 Socket Bolt
222 C-500-SS-222 Pedal Link 302 C-500-SS-302 Bolt
223 C-500-SS-223 Plunger Piston 303 C-500-SS-303 Arm Pin
224 C-500-SS-224 Spring Cap 304 C-500-SS-304 Washer
225 C-500-SS-225 Return Spring 305 C-500-SS-305 Bolt
226 C-500-SS-226 Pedal Pin 306 C-500-SS-306 Reservoir Housing
307 C-500-SS-307 Locking Swivel Caster
Replacement Parts Kits:
308 C-500-SS-308 Swivel Caster
901 C-500-SS-901 Seal Kit 309 C-500-SS-308 Rigid Caster
941 C-500-SS-941 Cylinder Assembly 310 C-500-SS-310 Bolt
942 C-500-SS-942 Pump Assembly
