BOL, manual
Copyright 2014 Vestil Manufacturing Co. Page 3 of 4
Installation Instructions:
Select anchor bolts appropriate for your bollard from the table below:
1. Place the bollard in the desired installation location.
2. The base plate of each bollard includes 4 bolt holes/slots. Mark the concrete with the location of each bo
lt
hole.
3.
Using a hammer drill and either a
3
/
8
in.or
3
/
4
in. masonry bit based on the necessary bolt hole diameter
indicated in the table above, drill a hole to the appropriate depth in the concrete (also indicated
in table).
4.
Set the bollard in place and align the bolt holes in the base plate with the holes drilled into the conc
rete.
5.
Put a flat washer followed by a hex nut onto the threaded end of each wedge anchor bolt; then tap the bo
lts
through the hole in the
base plate and into the drilled holes with a hammer. The nut should stick up above the
end of the bolt so that the hammer strikes the nut rather than the e
nd of the bolt.
6.
Tighten the nuts to expand the anchoring mechanism against the walls of the bolt holes. The bollard should
now be solidly anchored to the surface.
Inspections & Maintenance:
At least once per month:
Try to wiggle the bollard to determine the soundness of the connections between the anchor bolts an
d the
surfa
ce. If the bollard can wobble determine if any of the bolts are loose and tighten them. If the concrete around
the anchors is damaged and the anchor itself is loose, the bollard will have to be installed in another location.
Wipe dirt and grime from the su
rface of the bollard.
Model
*Ancho
r bolt
kit
Anch
or bolt
specifications
Diameter of
bolt hole
required
Depth of bolt
hole
BOL-##-2 BOL-ABK-3
3
/
8
in. x 4
1
/
4
in.
3
/
8
in. 2¼in.
BOL-##-4.5 BOL-ABK-4
3
/
4
in. x 4
1
/
4
in.
3
/
4
in. 3¼in.
BOL-##-5.5 BOL-ABK-4
3
/
4
in. x 4
1
/
4
in.
3
/
4
in. 3¼in.
BOL-##-6.5 BOL-ABK-4
3
/
4
in. x 4
1
/
4
in.
3
/
4
in. 3¼in.
BOL-##-8.5 BOL-
A
BK-4
3
/
4
in. x 4
1
/
4
in.
3
/
4
in. 3¼in.
*
*Anchor bolt kits are not included, but must be purchased separately.
