Step 4 : Enga ge the b eam with the ton gs. Tu rn the handl e clockwise until the clamp fi rmly gra sps the beam.
Each clamping arm i s formed to include an interior notch. These notches receive the top of an I-beam. Tighten
the clamp until the top of the beam contacts all four of the clamping arms within the notches as shown in photos 3
and 4. The angle d teeth (circled in photo 5) allow the clamping arms to engage the underside of the top of an I-
beam. Adjust the position of the tongs to allow all 4 teeth to make solid contact with the beam.
Firm contact between
beam and notche
s in
the clamping arms.
Page 6 of 11
Copyright 2010 Vestil Manufacturing Corp.
Step 5
: Test the balan ce of the beam i n the clam p. Gra sp the h oist hook to stabili ze the l ift (see ph oto 6), and
raise the beam just a few inches from the ground (or other supporting surface). The beam is improperly balanced
if it slides or hang s lower on one side
. If improperly balanced, return the beam to the grou nd/supporting surface
and immobilize it. Repo sition the clam p to improve balance by moving the cl amp slightly towa rds the e nd that
hung lower during the te st; then raise the obj ect again to see if the be am is balanced. DO NOT proceed to the
next step unt il the load i s properly balanced and st abilized. DO NOT use the cl amp if you cannot achieve a
balanced hold of the beam; use a different device to lift and move the beam.
ļ If a single clamp cannot balance the beam, use a combination of two or more clamps. Fo r instance, you
could connect a chain sling to the hoist hook, and attach a beam hook to each end of the sling via safety
hooks. Afterwards, retest the balance of the beam according to the process described in Step 5. Raise the
beam ONLY after achieving proper balance.
4
5
7
This end of the
beam ha ngs lower
than the other.
Return the beam to
the g round or
supporting s urface
and rep osition the
tongs by moving
them closer to thi s
end.
3
6
