TABLE OF CONTENTS Rev. 7/25/2022 AS-series anchor bolts, MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Co. Page 3 of 6
TORQUE SPECIFICATIONS
Anchor model no.
Anchor
diameter
Torque Value Anchor model no.
Anchor
diameter
Torque Value
AS-383
3/8” 25 – 30 lb∙ft
AS-584
5/8” 75 – 90 lb∙ft
AS-383-4PK
3/8” 25 – 30 lb∙ft
AS-584-4PK
5/8” 75 – 90 lb∙ft
AS-124
1/2” 50 – 60 lb∙ft
AS-344
3/4” 150 – 175 lb∙ft
AS-124-4PK
1/2” 50 – 60 lb∙ft
AS-344-4PK
3/4” 150 – 175 lb∙ft
AS-125
1/2” 50 – 60 lb∙ft
AS-346
3/4” 150 – 175 lb∙ft
AS-125-4PK
1/2” 50 – 60 lb∙ft
AS-346-4PK
3/4” 150 – 175 lb∙ft
SPECIFICATIONS
Information about each wedge anchor or wedge anchor kit is provided on Vestil’s website at
https://www.vestil.com/product.php?FID=1442
. The following table also provides anchor bolt
dimensions and other relevant for each model number.
Anchor Bolt
Model No.
Nominal Size
Dia. x Length
Description
Thread/
Sleeve
Dia.
Fixture hole
diameter
Overall
Length
Sleeve
Length
Min.
embed
-ment
depth
Weight
Each
AS-383 3/8" x 3"
Wedge anchor,
single
3/8" 1/2” 3" 0.75" 1.5” 0.1 lb.
AS-383-4PK 3/8" x 3" (4PK)
Wedge anchor,
4 pack
3/8" 1/2” 3" 0.75" 1.5” 0.4 lb.
AS-124 1/2” x 4
1
/
2
”
Sleeve anchor,
single
1/2” 5/8” 4.5” 3.75” 2.25” 0.2 lb.
AS-124-4PK
1/2” x 4
1
/
2
”
(4PK)
Sleeve anchor,
single
1/2” 5/8” 4.5” 3.75” 2.25” 0.8 lb.
AS-125 1/2" x 5½"
Wedge anchor,
single
1/2" 5/8” 5.5" 0.75" 2.25” 0.3 lb.
AS-125-4PK
1/2" x 5½"
(4PK)
Wedge anchor,
4 pack
1/2" 5/8” 5.5" 0.75" 2.25” 1.1 lb.
AS-344 3/4" x 4¼"
Wedge anchor,
single
3/4" 7/8” 4.25" 1.125" 3.375” 0.6 lb.
AS-344-4PK
3/4" x 4¼"
(4PK)
Wedge anchor,
4 pack
3/4" 7/8” 4.25" 1.125" 3.375” 2.4 lb.
AS-346 3/4" x 7"
Sleeve anchor,
single
3/4" 7/8” 7" 5.75" 3.25” 1.0 lb.
AS-346-4PK
3/4" x 7"
(4PK)
Sleeve anchor,
4 pack
3/4" 7/8” 7" 5.75" 3.25” 3.5 lb.
AS-584 5/8" x 5"
Sleeve anchor,
single
5/8" 3/4” 5" 4" 2.75” 0.4 lb.
AS-584-4PK 5/8" x 5" (4PK)
Sleeve anchor,
4 pack
5/8" 3/4” 5" 4" 2.75” 1.6 lb.
NOTE: 1” = 2.54cm; 1 kg = 2.2 lb.
Masonry
drill bits
Nominal Size
Dia. x Length
Description
Thread/
Sleeve
Dia.
Overall
Length
Weight
Each
(oz.)
Weight
Each
(lb.)
BIT-3/8 3/8" x 6" Concrete drill bit 3/8" 6" 1.7 oz. 0.106 lb.
BIT-1/2 1/2" x 6" Concrete drill bit 1/2" 6" 3.0 oz. 0.185 lb.
BIT-3/4 3/4" x 6" Concrete drill bit 3/4" 6" 6.4 oz. 0.401 lb.
