Hitch
end
3
FIG. 1: Front View of Fully Assembled Shed &
Parts List
6
6
4
5
2
1
7
Truck
connection
end
Steering Shaft
(not part of tow
bar assembly)
Drive
wheels
Tow bar accessory
ALL-T lift truck
Nylon hook strap
B
C
steering
shaft
wheel shaft
Slide the wheels off of the wheel shaft.
A
Remove the lug nut
and lock washer
that fastens each
drive wheel to the
wheel shaft.
Attaching the Tow Bar (ALL-TTB) to ALL-T-series Lift Trucks
Item
no.
Description
Quantity
1
7/16in. – 14 x 2.5in. bolt
2
2
5/8in. – 11 x 3.5in. bolt
1
3
1/2in. – 13 x 1in.
2
4
7/16in. – 14 nylock nut
2
5
5/8in. – 11 nylock nut
1
6
1/2in. – 13 nylock nut
2
7
1/4in. – 20 x 3in. bolt
2
8
1/4in. – 20 nylock nut
2
Step 1: Remove the drive wheels to expose the wheel shaft.
